3 Pin 1500mA 100V CCTV DC 12V Power Adapter With Short Circuit Protection
Quick Detail:
15W constant voltage power supply leakage Current: 0.25mA Material: ABS+PC 100% aging test before shipment 50,000 hours MTBF Short Circuit Protection Humidity: 5% to 95% Non-Condensing Certificate: CE & RoHS OEM/ODM welcomeFeatures:
o Universal Input 100~240VAC 50/60Hz
o Small volume, light weight, high efficiency.
o Ripple & Noise: 1% of Output Voltage
o Leakage Current: 0.25mA
o Output Voltage: 12V
o Output Current:1500mA
o Power: 18Watt
o No load power Consumption
o Working Temperature:0-40°C Max
o Efficiency:78%Min
o High Efficiency
o Short Circuit Protection
o Over Voltage Protection
o Over Current Protection
o Green Circuit Design
o Cooling by free air convection.
o 100% Full load burn-in test.
o One year warranty.
Weight: 90g
Dimensions: 75.0 x 29.0 x 43.0mm
o Accurate information and descriptions.
o All orders are shipped on time.
o All items are fully inspected prior to shipping to meet international standards by our QC staffs.
o All items are with CE RoHS approval to ensure the products quality.
1.Best quality:we have the most professional and experienced engineers and strict QA and QC System
2.Best Price:Products are produced in our factory,so we are entitled to control the quality well and reduce
the cost to offer more competitive price and excellent quality.
3.Strong production capacity:over 200000 pieces per months.
4.Prompt delivery time:3-5 working days.
5.Professional technological team: Your tailored/customized connectors and package are welcome.
6.Good after_sales service: 1 year warranty.
7.Leading supplier:we have more than 10 years experiences in power supply industry.
Specification:
|
OUTPUT |
DC VOLTAGE |
12V |
|
OUTPUT POWER |
15W |
|
|
CURRENT RANGE |
1500mA |
|
|
INPUT |
VOLTAGE RANGE |
110VAC -264V AC |
|
FREQUENCY RANGE |
50-60Hz |
|
|
EFFICIENCY(Typ.) |
78% |
|
|
ENVIRONMENT |
WORKING TEMP. |
-0°C ~ +40°C (Refer to output load derating curve) |
|
STORAGE TEMP.,HUMIDITY |
-10°C ~ +70°C 10~95% RH |
|
|
COOLING METHOD |
BY FREE AIR CONVECTION |
How to Install?
Connect power supply to the supplied unit. Power supply must be connected to a working electrical AC line with a voltage of 100-240V. Do not install power supply in locations with high humidity, dust or strong direct sunlight. The power supply should be installed in a location with good airflow. Power supply can only be installed indoors.
Applications:
1. CCTV security, door access, digital camera, etc.
2. POS machine, mini printing machine, etc.
3. Electronic scale, flowerpot etc.
4. LED strip, LED lighting etc.
Shipping terms
|
1.FCL - Full Container Loading 2.LCL - Less Container Loading 3.EXPRESS 4.Air Shipment |
Payment terms
|
1.T/T 2.L/C 3.PayPal 4.West Union |
