Certification:CE,ROHS
RoHS Desktop 48W 12 Volt 4 Amp AC DC Power Adapter With AC Cord For Satellite Receiver
Quick Detail:
12V 4A power supply Type: desktop type AC plug: EU,US,AUS,UK,CN etc. DC plug: 5.5*2.1mm,5.5*2.5mm,3.5*1.35mm, micro/mini usb etc. Material:plastic materials Certificate: CE & RoHS leakage Current: 0.25mA Safety : SCP OCP OVP OEM/ODM welcomeFeatures:
o Output Voltage: 12V
o Output Current: 4000mA
o Power: 48Watt
o Universal Input 100~240VAC 50/60Hz
o Small volume, light weight, high efficiency.
o Cooling by free air convection.
o 100% Full load burn-in test.
o One year warranty.
o Ripple & Noise: 1% of Output Voltage
o Leakage Current: 0.25mA
o No load power Consumption
o Working Temperature:0-40°C Max
o Efficiency:86%Min
o High Efficiency
o Short Circuit Protection
o Over Voltage Protection
o Over Current Protection
o Green Circuit Design
Weight: 370g
o Dimensions: 119.0 x52.0 x 32.0mm
o Accurate information and descriptions.
o All orders are shipped on time.
o All items are fully inspected prior to shipping to meet international standards by our QC staffs.
o All items are with CE RoHS approval to ensure the products quality.
Packing details:
1 piece per white box
40PCS/CTN
G.W.: 11.5KGS/CTN
N.W.: 12.5KGS/CTN
Specification:
|
OUTPUT |
DC VOLTAGE |
12V |
|
OUTPUT POWER |
48W |
|
|
CURRENT RANGE |
4000mA |
|
|
INPUT |
VOLTAGE RANGE |
110VAC -264V AC |
|
FREQUENCY RANGE |
50-60Hz |
|
|
EFFICIENCY(Typ.) |
86% |
|
|
ENVIRONMENT |
WORKING TEMP. |
-0°C ~ +40°C (Refer to output load derating curve) |
|
STORAGE TEMP.,HUMIDITY |
-10°C ~ +70°C 10~95% RH |
|
|
COOLING METHOD |
BY FREE AIR CONVECTION |
How to Install?
Before connecting check whether the power supply fullfields electrical specification (output voltage and current). Also check the socket type and its polarity. Connect power supply to the supplied unit. Power supply must be connected to a working electrical AC line with a voltage of 100-240V. Do not install power supply in locations with high humidity, dust or strong direct sunlight. The power supply should be installed in a location with good airflow. Power supply can only be installed indoors. AC wire should connect tight with adapter socket, in case poor contact socket.
Applications:
1. CCTV security, door access, digital camera, etc.
2. POS machine, mini printing machine, etc.
3. Electronic scale, flowerpot etc.
4. LED strip, LED lighting etc.
Shipping terms
|
1.FCL - Full Container Loading 2.LCL - Less Container Loading 3.EXPRESS 4.Air Shipment |
Payment terms
|
1.T/T 2.L/C 3.PayPal 4.West Union |
