Plastic Bottle Cold Filling Production Line For Carbonated Beverage Drinks

Delivery Time:20-40day after getting the bottle sample
Certification:CE,ISO9001:2001,BV

Plastic Bottle Cold Filling Production Line For Carbonated Beverage Drinks

Quick Detail:

Unattached electric control box,convenient and safe With air convey and caps feeding system& return tanks   Filling temperature: 5degree PLC/inverse: Japanese Mitsubishi/by order Bottle volume: 250ml-2500ml Filling capacity: we can offer 2000bph-20,000bph After service: with professional engineer to customer factory to installment and train Material: sus 304/316 Packing: wooden package Filling level: up to customer, 2mm from the bottle neck, whatever Voltage: 380V 50Hz/ by order Power: 5-18KW

Description:

Automatic 3000bottles per hour PET bottle carbonated/ soda/ gas/ soft drink cold filling machine

1. This bottling machine is a unique design combining the three machines of bottle washing, filling and capping in one to decrease main power, to save space and to diminish the air pollution among the three machines.

2. It is applicable for carbonated drink filled in plastic bottles and capped with plastic caps, with optional capacity from 2000BPH to 28000BPH.

3. It is easy to change the shape of bottles, which can be done by changing the thumb wheel without adjusting the height of the machine.

4. Adopting suspensory transmission gear can easily upkeep and be repaired.

5. The machine case and the parts contacting with the materials are made of stainless steel which ensures the good external look and easy washing.

6. It uses frequency changer to control the main machine motor. And it has an output number indicating function which is easy to control the adjustment of the output.

Technical data
Model	DCGF18186	DCGF24248	DCGF32328
Number of washing, filling, capping	18-18-6	24-24-8	32-32-8
Capacity;bottle (600ml)/hour	3000-5000	6000-7000	8000-10000
Suitable bottle size (mm)	φ=50-108  H=170-340    330ml-2.25L
Pressure (kg/cm2)	2~3
Power (kw)	5kw	6kw	8kw
Overall size (mm) (LxWxH)	2350*1700*2300	3200*1900*2300	4300*2000*2300
Weight(kg)	3800	5000	6000
Technical data
Model	DCGF404010	DCGF505012	DCGF606015
Number of washing, filling, capping	40-40-10	50-50-12	60-60-15
Capacity;bottle (600ml)/hour	10000-12000	12000-15000	15000-18000
Suitable bottle size (mm)
