ISO Stainless Steel Water Barrels Filling Machine , 5 Gallon 20L 300BPH
Quick Detail:
Filling temperature: 20-40degree Bottle volume: 5 gallon 20L Filling capacity: we can offer 100bph-1200bph After service: with professional engineer to customer factory to installment and train Material: sus 304/316 Packing: wooden package Voltage: 380V 50Hz/ by order Power: 5-18KW
Description:
Automatic 3/5 gallon bottle washing filling capping machine
3-5GallonBarrel Water Line/ Filling Machine adopts Famous electrical complement and Made by Food stage SS 304.Working stable and reliable.
1. The 5Gallon Filling Machine is composed of barrel washer,barrel filling machine and barrel sealer into one unit.
2. Especially for filling drinking water of 3 and 5 gallons. It is an idea filling line to produce mineral water, distilled water and purified water.
3.The whole line is made of superior stainless steel, anticorrosive and easy to clean.
4. Only two operators are needed for a line, which is wholly automatic barreled.
5. Full-auto or semi-auto barrel de-capper, full-auto leakage inspection,full-auto barrel outside brusher, full-auto barrel loading machine, steam shrinking film machine and coding system can be choose depends on what customer\'s need.
Technical standard
|
Model |
QGF100 |
QGF250 |
QGF300 |
QGF450 |
QGF600 |
QGF900 |
QGF1200 |
|
Filling heads |
1 |
2 |
2 |
3 |
4 |
6 |
10 |
|
Volume(L) |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
|
Barrel size(mm) |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
|
Capacity(b/h) |
100 |
250 |
300 |
450 |
600 |
900 |
1200 |
|
Gas pressure(Mpa) |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
|
Gas consumption (m/min) |
0.37 |
0.37 |
0.6 |
0.8 |
1 |
1.5 |
1.8 |
|
Motor power(kw) |
1.38 |
1.75 |
3.8 |
3.8 |
7.5 |
9.75 |
13.5 |
|
Weight(kg) |
680 |
800 |
1500 |
2100 |
3000 |
3500 |
4500 |
