Home UPS,Inverter,Pure Sine Wave Inverter

MODEL

GF Inverter 2012

GF Inverter 3012

GF Inverter 2024

GF Inverter 3024

CAPACITY

2000 VA/ 2000 W

3000 VA/ 3000 W

2000 VA/ 2000 W

3000 VA/ 3000 W

INPUT

Voltage

Nominal Voltage

230 VAC

Acceptable Voltage Range

184 - 253 VAC (±4%)
Max input AC Voltage 270VAC

FrequencyRange

50 Hz (auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)

230 VAC±10%

FrequencyRange(Batt. Mode)

50 Hz ±1 Hz

Transfer Time

10 ms typical

Waveform (Batt. Mode)

Pure Sine Wave

BATTERY

BatteryVoltage

12 VDC

24 VDC

Floating Charge Voltage

13.4 VDC ± 2%

26.8 VDC ± 2%

Low Battery Alarm Voltage

10.8 VDC ± 2%

21.6 VDC ± 2%

Shutdown Voltage

10.0 VDC ± 2%

20.0 VDC ± 2%

Overcharge Protection

15.0 VDC ± 2%

30.0 VDC ± 2%

Maximum Charge Current

70 A

70 A

35 A

35 A

PROTECTION

Full Protection

Overload and short circuit breaker

COMMUNICATION & OTHER

Communication

RJ11(Used for factory testing.No customer interface available)

Safety Certiffcation

Compliance with Ul458

CE(EN60950)

EMI Classification

FCC, CLASS A

EN50091-2, CLASS A

Audible Noise

60dB max

ALARM

Low Baery

beep 0.5s every 5 s

Overload

beep 0.5s every 5 s

Over Tempe
