1)Sensitivity selector
2)12VDC or 24VDC available
3) 20 A standard charging current.
4)Modified sine wave inverter
This is a compact inverter system for home and office appliances. Its selectable wide and narrow input voltage switch featurs flexibility for users. this sine inverter is perfect to connect either generators or computer-related devices. It\'s a green subsitution for generators without air pollution. It also provides overload and short circuit protection.
|
MODEL |
HF Inverter 1K |
HF Inverter 1.2K |
HF Inverter 2K |
HF Inverter 2.4K |
|
CAPACITY |
1000 VA/ 600 W |
1200 VA/ 720 W |
2000 VA/ 1200 W |
2400 VA/ 1440 W |
|
INPUT |
||||
|
Voltage |
Nominal Voltage |
220/230/240 VAC |
||
|
Acceptable Voltage Range |
162 - 290 VAC (UPS mode) |
|||
|
FrequencyRange |
50 Hz (auto sensing) |
|||
|
OUTPUT |
||||
|
AC Voltage Regulation (Batt. Mode) |
±10% |
|||
|
FrequencyRange(Batt. Mode) |
50 Hz ±1 Hz |
|||
|
Transfer Time |
10 ms typical |
|||
|
Waveform (Batt. Mode) |
Simulated Sine Wave |
|||
|
BATTERY |
||||
|
BatteryVoltage |
12 VDC |
24 VDC |
||
|
Floating Charge Voltage |
13.4 VDC ± 2% |
26.8 VDC ± 2% |
||
|
Low Battery Alarm Voltage |
10.8 VDC ± 2% |
21.6 VDC ± 2% |
||
|
Shutdown Voltage |
10.0 VDC ± 2% |
20.0 VDC ± 2% |
||
|
Overcharge Protection |
15.0 VDC ± 2% |
30.0 VDC ± 2% |
||
|
Maximum Charge Current |
10 A |
10 Aor 20 A |
10 A |
10 Aor 20 A |
|
PROTECTION |
||||
|
Full Protection |
Overload and short circuit protection |
|||
|
INDICATORS |
||||
|
Line Mode |
Green lighting |
|||
|
BatteryMode |
Yellow lighting |
|||
|
Low Battery |
Yellow flashing every 2 seconds |
|||
|
Shutdown Mode |
Yellow flashing every 5 seconds |
|||
|
Charging Mode at Power On |
Green flashing every 2 seconds |
|||
|
Charging Mod |
