Home > Products > Stage LED Screens > High Brightness P6 Indoor Full Color Stage LED Screens Video Wall 27777dots/m2 SMD3528
High Brightness P6 Indoor Full Color Stage LED Screens Video Wall 27777dots/m2 SMD3528
- T/T L/C D/P D/A
- 7 days
You May Like
-
Indoor Full Color LED Display For Advertising , Epistar / Silan Rental Stage Led Screens
-
Programmable Wide color Gamut Traffic Led Signs /screen For traffic guide
-
SMD 3528 HD Full Color Stage Background Led Display Screen Rental , Light Weight P6.4 / P8 / P10
-
Energy Saving Fixed Outdoor Traffic Led Sign / billboard/panel with Long Service Life for subway/ ra
-
Electronic Outdoor Solar Traffic Led Signs For Highway Waterproof
-
Solar Powered 4R2G Electronic Led Signs/board/ screen For Traffic Guidelines
Product Details
Brand Name | Xiwan | Place of Origin | China | |
Model Number | NA60070/NA60170, NA64070/NA64170 |
Product Description
Certification:CE,Rohs SGS
High Brightness P6 Indoor Full Color Stage LED Screens Video Wall 27777dots/m2 SMD3528
Quick Detail:
Hanging beam structural design makes it easy and fast for installation Neat and Hidden Wiring allow the display more tidy and beautiful. It can establish at business square, airport and station etc. Qualified LED core from Epistars, Silan and other big brand.Description:
N series P6mm LED display is indoor LED display with outdoor full color LED display features. If people are close to the screen, in order to achieve clear imaging, it must use small pitch display. But normally, indoor led display can\'t catch up with the outdoors on water resistance and brightness.
For the special consideration, we made P6mm indoor full color display:
1.make a transparent glass cover on the screen to keep it working normally in bad weather. At meantime, it doesn’t affect viewing;
2.The driving method is 1/4 duty(indoor display regularly is 1/8 duty), improve brightness, reach the brightness needs in outdoor environment use.
Qualified LED core from Epistars, Silan and other big brand.
Qualified LED driving from Meanwell
Applications:
Advertising media, sports stadiums, airport station, business establishments, and public square
Specifications:
Item No. |
NA60070/NA60170 |
NA64070/NA64170 |
Pixel Pitch (mm) |
P6 |
P6.4 |
Application |
indoor |
indoor |
Module resolution |
32*16 |
40*40 |
Module size |
192*96 |
256*256 |
Pixel combination |
SMD3528 |
SMD3528 |
Driving way |
1/8 |
1/8 |
Module weight (Kg) |
0.16Kg |
0.63Kg |
Body size |
768*768 |
768*768 |
Cabinet resolution |
128*128 |
120*120 |
Cabinet pixel |
16384 |
14400 |
The number of modules |
32 |
9 |
Box type |
Simple box/Fixed installation iron box |
Simple box/Fixed installation iron box |
Body weight (Kg) |
22/32 |
28/38 |
The whole screen pixel density |
27777 |
24414 |
Average Power Consumption (WATT/Cabinet) |
195W/mm |
200W/mm |
The maximum power (W/mm) |
≤690W/mm |
≤700W/mm |
The input power(W/mm) |
865W/mm |
875W/mm |
Brightness (nita nits) |
2000 |
2300 |
Competitive Advantage:
1. Hanging beam structural design makes it easy and fast for installation
2.Neat and Hidden Wiring allow the display more tidy and beautiful.
3. Hanging beam and the base come to unity, That is, hanging beam could be used as a base when we need to install led display on the floor. Even no back frame, the base can support the whole display if only the display\'s weight is 4m more or less. Efficiently
utilize reso
