Home Electric Magnetic Water Filters with Output DC 12V 3A 36W for Launder Clothes
PRODUCT PURPOSE
ECO Laundry Generation II is an environmentally friendly appliance intended for using in a residential laundry facility.
ECO Laundry Generation II is designed to work with your washing machine, adopts magnetizing principle to treat the tap water firstly, then mixed active oxygen and silver ions into the magnetized water used for laundry.The processed water can wash clothes cleanly and kill bacteria on clothes without leaving any residual detergent.
ECO Laundry Generation IIhas the main functions as below:
Soft the water
Sterilization and disinfection;
Decontamination and purification;
Energy conservation and environmental protection
No pollution
The operation of ECO Laundry Generation II is easy and convenient. As long as you install ECO Laundry Generation II properly, you simply need to operate your washing machine following manufacturer’s operation instructions. ECO Laundry Generation II will start working automatically when the washing machine starts to work, and it will automatically turn off when the washing machine stops operation.
TECHNICAL SPECIFICATION TABLE
|
Model |
ECO Laundry Generation II(OLK-W-02) |
|
Electrical |
Input: AC 100-240V/50-60Hz Output: DC 12V 3A 36W |
|
Ozone Concentration |
0.4 ~ 0.6 mg /L |
|
Water Pressure |
Minimum:15 psi Maximum:75psi |
|
Operating Temperature |
0℃~78℃ |
|
Product dimension |
477mmX242mmX103mm |
|
NetWeight |
2.0 Kgs |
USE & SAFETY CONSIDERATION
Before using, please read the User’s Manual carefully.
Disconnect ALL power before servicing.
Do not operate the unit with the cover removed.
Maximum water inlet pressure is 75psi.
Use the supplied new hose when connect the ECO Laundry Generation II unit to your washing machine. You should replace any existing washing machine hose that is more than 2 years old, with a new one.
To prevent leakage caused by back-flow from the washing machine, do not leave your water hose disconnected. Simply turn the water off at the valve / faucet on the wall, leaving the hose connected.
Use a soft cloth dampened with water. Do not clean your ECO Laundry Generation II with harsh chemicals, abrasives or cleansers.
Do not mount the ECO Laundry Generation II unit vertically or at an angle.
ECO Laundry Generation II is designed for residential use only and is not intended for use in a commercial or industrial setting.
ECO Laundry Generation II can work normally in the temperature category 0℃~78℃, without components breakdown.
Replacement Parts
|
Part Name |
Part No. |
|
|
⑥ |
Silver Ion Probe |
ECO Laundry-P- SI |
|
⑧ |
Control Module |
ECO Laundry-P- PCB |
|
⑨ |
PCO Cell |
ECO Laundry-P- PCO |
|
11 |
Oxidizing Module |
ECO Laundry-P- OM |
INSTALLATION REQUIREMENTS
Electrical Requirements
ECO Laundry GenerationII requires 120Volt 60Hz power on a 15amp fuse or Circuit Breaker.
A dedicated electrical circuit, equipped with an approved GFCI outlet, is recommended for supplying power to your ECO Laundry Generation II.
NEVER use an extension cord or a power adapter other than the one provided with ECO Laundry Generation II.
Water Requirements
Water pressure of 10 to 75psi is required to correctly operate your ECO Laundry Generation II.
To avoid the possibility of water damage (i.e. a hose leak) it is recommended that you always
