Q345B Steel Tower Crane Sections Tower Crane Section F0 / 23C L46A1

1. Plate(chip) crane mast section

2. Exchangeable standard section

3. Model: F0/23C(L46A1)

4. Dimensions: 1,600mmX1,600mmX3,000mm

5. Material: Q345B steel

6. Weight: 1300kgs

 Description:

 The mast sections in the model: F0/23C(L46A1),F0/23B,H3/36B,L68B1,L68B2

 The plate crane mast section apply POTAIN's F0/23C standards . The main chord adopts the 180mmX180mmX18 angle steel to produce  with high strength. The  ladder and platform made of HDG steel with strong weatherability.

Applications:

 Standard section used for conehead tower crancee and flat head tower crane

 Specifications:

1. Section dimension 1,600mmX1,600mmX3,000mm

2. Forged fish plate be jointed by  diameter 50mm pin roll.

3. The main chord be made of 180mmX180mmX18 angle steel

 Competitive Advantage:

1. The plated type standard section can be exchangeable with POTAIN's. F0/23C.

2.The structual parts be dealed with shot blasting machine to ensure the cleaning of the workpiece surface for relieving of internal stress, increasing the intensity of steel and adhesive force of paint film. The primer epoxy and polyurethane finish coat be painted separately on it with weatherability.
