40t / 100t / 200t Four-Column Hydraulic Press With One Cylinder

FOB Price

US$ 1000 - 1000 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KLT		Place of Origin	China
Model Number	YK32

Product Description

Delivery Time:15-30 days
Certification:ISO & CE

40t / 100t / 200t Four-Column Hydraulic Press With One Cylinder

Quick Detail:

Three-beam, 4 posit structure hydraulic press machine High speed press machine Press machine can be customized with one cylinder, two cylinders, three cylinders and four cylinders. Cold or heat hydraulic oil press machine Three operation model, manual, semi-auto and auto; equipped hands operation button and emergency stop button Apply to deep drawing, winding, stamping and pressing working process Equipped Mitsubishi PLC and CNC control system Apply to industry of steel parts, plastics moulding, powder parts compacting, and etc. . Hydraulic press model are from 100 ton, 160 ton, 200 ton,315 ton,500 ton, 630 ton, 1000 to 2000 ton.

Description:

1. YK32 series four-column high speed hydraulic press has wide generality.
2. It is suitable for the press fitting of plasticity material and powder product; the straightening of shaft components and axle sleeve parts; the press fitting of electrical components; the stretch of small plate-shaped parts; molding blanking; coining and overprinting.
3. The working speed of this equipment is 3 to 4 times faster than that of ordinary hydraulic press (fast down: 180-250mm/s, slow speed: 7-25mm/s).
4. It adopts the operation of both-hand buttons.
5. The pressure can be regulated within limits.
6. This machine is easy and safe to operate. It also has security light curtains to protect operators.
7. It has the features of power saving, high efficiency and speed.

Applications:

It is suitable for the suppression of plastic materials, powder products and electrical parts, and the calibration of the parts like bearings and other similar parts. It is also suitable for small plate-shaped parts of the drawing, forming and blanking, creasing, embossing and other craft uses.

Specifications:

Type Item	Unit	2.5T	6.3T	10T	16T	25T	40T	63T	100T	160T	200T
Nominal pressure	KN	25	63	100	160	250	400	630	1000	1600	2000
Max. pressure of liquid	Mpa	4.9	12.5	8.1	13	20.3	23	18.5	26.3	19.9	25
Max. opening height	mm	300	450	500	500
