Good Duct Rodder, 4.5mm-16mm Duct Rodder ,60-500m Duct Rodde

Good Duct Rodder, 4.5mm-16mm Duct Rodder ,60-500m Duct Rodde photo-1
Good Duct Rodder, 4.5mm-16mm Duct Rodder ,60-500m Duct Rodde photo-2
US$ 20 - 1050 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Wuzhou
Place of Origin:
China
Model Number:
wz
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Brand Name Wuzhou
Place of Origin China
Model Number wz

Duct Rodders applies in tow lead-rope through a pipe, it is auxiliary means. Surface smooth and high resilience, so the FRP perforator with ease passes the narrow channel. perforator consists of two parts: the glass fiber strengthen the level, the high-pressured low density polyethylene protective layer(smooth, firm ,can resist the adverse circumstance). It has time-savingreducing effort, improving efficiency, etc ,And can be used for telecom cables, cable pipe and cleaning and plastic pipe of cloths to put. when use draws out the FPR pole by the pulley, then with a corresponding metal joint, penetrates in the pipeline. When cleaning, guide-head will drive cleaning tools to clean the pipe; When arranges the cable, you may first leads the steel wire or the iron wire, then enters the pipe with the steel wire or the iron wire hauling cable.



Propertyvalue

Model specification4.5mm,6mm,8mm,10mm,11mm,12mm,13mm,14mm,15mm,16mmfor your choice, and we can also accept OEM order

Length30,50,60,80,100,120,150,180,200,250,300,350,400,450,500 meters for choice.

MaterialFiberglass (inner) and high density polytgtkebe(outer)

Density>1.9gr/cm3

Working temperature- 40 to + 80

Minimum pulling strength4000 N±5%

Tensile Modulus>46.500Mpa

Consistency of rod137gr/m

Flexural Modulus>46.500Mpa

Elongation at Break2.5-3%

Min. Bending Radius388m

Tensile Strength>15N/mm2

Environmental Stress & Crack Resistance>1000hr



Our duct rodders lineup includes detectable duct rodders, non detectable duct rodders, cobra duct rodders, python duct rodders and mini-cobra duct rodders by manufacture such as jameson, DCD, condux and GMP Tools.

Condux Duct Rodders:

Combine ease of operation and reliable performance to help increase the efficiency of your rodding operations.

Condux Duct Rodders combine ease of operation and reliable performance to help increase the efficiency of yourrodding operations.

Condux offers three types of duct rod: Cobra, Python and Mini-Cobra.

Condux Duct Rodders Catalogs

GMP Duct Rodders:

GMP Duct Rodders are essential tools for underground tasks such as cleaning and locating ducts, threading lines or pulling cables.

Rodders come equipped with a male threaded end fitting and tapered head on the leading end and a female threaded fitting on the back end.

GMP Duct Rodders Catalogs

DCD Duct Rodders:

DCD Duct Rodders offers one of the most comprehensive range of Duct Rodders available anywhere in the world - from the smallest 1/8" diameter Fish tapes to the rugged 1/2" Duct Rodders.
