5W / 3W LED Explosion Proof Lights For Flammable / Explosive Place
Quick Detail:
Place of Origin: Zhejiang, China (Mainland) Brand
Number: CBRZ603
Light Source: LED
Watt: 5W/3W
Material: aluminum alloy
Payment Terms:T/T,L/C
Certificate:ISO9001
Applications:
Suitable for flammable and explosive place security work, for a variety of indoor and outdoor workplaces. China\'s coal industry, China petroleum, Sinopec, electricity, metallurgy, railway, steel, shipbuilding, military, aerospace, public security fire control, chemical industry and the use of large enterprise fixed lighting needs.
Features:
Explosion-proof function:it has been certificated by state authority,reaching the highest explosion-proof grade of safety type.It completely according to the national explosion-proof standard,can work safely in flammable and explosive environment. High-light efficiency and energy-saving:Select the latest green and high-power white LED solid light source.High-light efficiency and Long-service life,up to 100000 hours.It can be achieved long-term maintenance free,,soft lighting,uniformity illumination,no glare,to help preserve eyes from strain,improve work efficiency.The power consumption is only 20% of incandescent lamp with the same light flux,economic and environmental. Application Environment:The shell adopts light-weight alloy materials and latest surface treatment technology.which is corrosion resistant,waterproof and dustproof;The transparency is made of imported bullet-proof glue material,,with high transparency ,good impact resistance,and can make the light work properly under various harsh environment. Installation:Adopt seating,walling,ceiling and other manners of installation;Small size and light weight,it is easy and convenient to install and can be indirectly leading by cables.Distribution Curve
Characteristics
|
NO. |
Light Source |
Rated Power(W) |
Luminouse flux(Lm) |
|
CBRZ603 |
LED |
5*1W |
300 |
|
3*1W |
180 |
||
|
Rated voltage: |
AC/DC85V~260V |
||
|
AC/DC12V~48V |
|||
|
Service Life: |
100000h |
||
|
Explosion-proof mark: |
Exe II T6 |
||
|
Enclosure: |
IP65 |
||
|
Insulation Class: |
I |
||
|
Protection Category: |
WF2 |
||
|
Inlet Thread: |
G3/4 |
||
|
Drop Cable: |
Ø6-Ø8mm |
||
|
Distance Ratio: |
1.2 |
||
|
Dimensions: |
Ø146*134mm(outline*hight) |
||
|
Total Weight: |
1.4kg |
Product Dimensions and Installation
