Ultrasonic Scaler

Model: SHEL-Y-B

Compatible with: EMS

• Touch Screen Ultrasonic Scaler - fingertip control for the ultimate in

hygiene and precise operation everytime.

• Detachable Handpiece autoclavable

• Automatic frequency tracking

• Scaling, Perio, Endo Function

• Add AutoBottle to provide an integral water supply

Could choose compatible with Satelec(Model SHEL-Y2-B)

Functional Characteristics

1. Assembled with excellent piezo-ceramic,the handpiece has high and long lasting power and generates little heat.

2. Digitally controlled,automatic frequency tracking ensures that the machine always works on the best frequency and more steadily.

3. The scaler tip is made of strong alloy material. The atomized spraying design forms the cavitations to achieve the cleaning purposes.

4. Ergonomic handpiece design adopts innovative structural patent, easy for long time use.

5. The shell of the handpiece is made of the imported medical plastic, ensuring the safety of patients.

6. The cable of the handpiece is made of imported silica gel tube, soft and durable.

7. Axis of the handpiece is made of high-quality titanium alloy, strong and durable.

8. Four different scaling tips for selection, meet different demand for teeth treatment.

9. The unique design of amplitude offers more convenience for operation.

10. Beautiful appearance, exquisite craft, small and light, easy operation.

11. Unique automatic amplitude compensation function, maximumly reduces patients discomfort.

12. The AutoBottle is used in conjunction with ultrasonic scaler machines to provide an integral water supply.

Specs

Adapter Input: 230V±22V 60Hz±1Hz

Main unit input: 30VDC 1.3A

Input power: ≤40VA

Main unit fuse: 1.6A/250V

Output power: 3W~20W

Output primary tip Vibration excursion: ≤100μm

Output tip Vibration frequency: 28kHz±3kHz

Output half-excursion force: 2N

Water pressure: 0.01MPa~0.5MPa (0.1bar~5bar)

Weight of main unit: 0.55kg

Type of protection against electric shock: Class II

Degree of protection against electric shock: Type BF applied part

Dimensions: 170mm x 140mm x 108mm
