Putty Spraying Machine

Putty spraying machine

Product Introduction

Putty spraying machine is a small machinery of mixing, pumping and spraying quality putty powder , is among the putty sprayer sprayer kind of major domestic and foreign production of a variety of decorating spray putty. Daily spray area up to 1500 square meters, suitable for housing protection, paint, paste and bottom slurry.

Putty spraying machine is suitable for coating materials: cement slurry. Thermal insulation, waterproofing materials, fireproof materials, insulation materials, sound-absorbing materials, putty, paint, white latex, lacquer, water, mud, and other water-soluble materials, plastic materials, the hourly easy spray 330m, work efficiency increased by 25 times

Basically no ash fall, save water, save material, can reduce the 20% cost or more. Mainly used in indoor and outdoor spraying, waterproof grout and waterproof surface coating, waterproof coating, grouting, ceiling painting, wall painting, paint spraying, landscape painting, embossed paint spraying, crafts spray, lacquer, rockery spray, sculpture spray can, acoustic material spraying and so on.

Advantage

1.simple,before putty we can use the mixer to mix putty , this uniform viscous putty both moderate the effects of artificial mixing than a lot better. 2.spray fast, if you use putty spraying machine, then a wall painting can only take a few minutes to complete, if the construction operation, then progress will be much slower.

3.spraying evenly, using putty sprayer, because the spray is used when a certain pressure and the thickness of the nozzle so the spray is better to master, there will be no uneven phenomenon, which do better than artificial.

4.save material, using putty sprayer, you can control the speed of the spraying machine and thickness,save material than manual.

Instructions

Putty spraying is reliable, adaptable, durable, easy-to-spray unit. Entire sprayer in the construction need only three individuals, namely a person transporting raw materials, a person controlled spray gun material, to assist another person to do the work (such as: assisting mobile leather tube), and the material, add water, stirring, transport and other processes are done automatically by the machine. Compared with the traditional artificial construction saves manpower, material and financial resources and precious time, and in the construction quality is also better than the traditional artificial construction, more assured.

Entire sprayer also installed security operations control system. When machine working, no matter which part fails, the whole machine will stop working, so that not only ensure the safety of construction workers, but also ensure the safety of the machine itself, but also a timely reminder of the staff came to troubleshoot and maintenance, saving valuable time as possible.

Technical Parameter

Model:SP10N
Voltage:220V
Power:3kw
Conveying flow:13L/min
Conveying pressure:30bar
Conveyingdistance:15m
Conveying height15m
Spraying pipe:25m
Hopper capacity:50L
Feeding Method: Mixer spices
Machine weight: 90kg
