Certification:LEAD FREE/ROHS COMPLIANT
Quick Detail:
SN74AHC245DBR OCTAL BUS TRANSCEIVERS WITH 3-STATE OUTPUTS
Description:
The ’AHC245 octal bus transceivers are designed for asynchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements.These devices allow data transmission from theA bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device sothat the buses are effectively isolated.To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pull up resistor; the minimum value of the resistor is determined by the current-sinking
capability of the driver.
Applications:
Operating Range 2-V to 5.5-V VCC
Latch-Up Performance Exceeds 250 mA Per JESD 17
Specifications:
|
Datasheets |
SN54/74AHC245 |
|
Product Photos |
20-SSOP |
|
Standard Package |
2,000 |
|
Category |
Integrated Circuits (ICs) |
|
Family |
Logic - Buffers, Drivers, Receivers, Transceivers |
|
Series |
74AHC |
|
Packaging |
Tape & Reel (TR) |
|
Logic Type |
Transceiver, Non-Inverting |
|
Number of Elements |
1 |
|
Number of Bits per Element |
8 |
|
Current - Output High, Low |
8mA, 8mA |
|
Voltage - Supply |
2 V ~ 5.5 V |
|
Operating Temperature |
-40°C ~ 85°C |
|
Mounting Type |
Surface Mount |
|
Package / Case |
20-SSOP (0.209\", 5.30mm Width) |
|
Supplier Device Package |
20-SSOP |
|
Dynamic Catalog |
74AHC |
|
Other Names |
296-4586-2 |
Competitive Advantage:
Warranty :180days for all goods
Free shipping:Order over $600 win a free shipment fee:goods weight below 3Kg.
Mega Source Electronics stocks components ready to ship. Hard to find, obsolete and highly allocated integrated circuits and semiconductors are all can be found by us.
Mega Source Electronics has established a well-developed logistics system and global logistics network, which can guarantee our service very quick, convenient and efficient.
Tag:
SN74AHC245DBRG4 SN74AHC245DBRE4 MARKING HA245
