Certification:LEAD FREE/ROHS COMPLIANT
Quick Detail:
EPM7128S Datasheet (PDF) - Altera Corporation - Programmable Logic Device Family
Description:
The MAX 7000 family of high-density, high-performance PLDs is based on Altera’s second-generation MAX architecture. Fabricated with advanced CMOS technology, the EEPROM-based MAX 7000 family provides 600 to 5,000 usable gates, ISP, pin-to-pin delays as fast as 5 ns, and counter speeds of up to 175.4 MHz. MAX 7000S devices in the -5, -6, -7, and -10 speed grades as well as MAX 7000 and MAX 7000E devices in -5, -6, -7, -10P, and -12P speed grades comply with the PCI Special Interest Group (PCI SIG) PCI Local Bus Specification, Revision 2.2. See Table 3 for available speed grades.
Applications:
Logic array blocks
Macrocells
Expander product terms (shareable and parallel)
Programmable interconnect array
I/O control blocks
Specifications:
Datasheets |
MAX 7000 Device Family Data Sheet |
Product Photos |
100-PQFP |
Standard Package |
66 |
Category |
Integrated Circuits (ICs) |
Family |
Embedded - CPLDs (Complex Programmable Logic Devices) |
Series |
MAX® 7000S |
Packaging |
Tray |
Programmable Type |
In System Programmable |
Delay Time tpd(1) Max |
15.0ns |
Voltage Supply - Internal |
4.75 V ~ 5.25 V |
Number of Logic Elements/Blocks |
8 |
Number of Macrocells |
128 |
Number of Gates |
2500 |
Number of I /O |
84 |
Operating Temperature |
0°C ~ 70°C |
Mounting Type |
Surface Mount |
Package / Case |
100-BQFP |
Supplier Device Package |
100-PQFP (14x20) |
Dynamic Catalog |
MAX® 7000 |
Other Names |
544-2038 |
Competitive Advantage:
Warranty :180days for all goods
Free shipping:Order over $600 win a free shipment fee:goods weight below 3Kg.
Mega Source Electronics stocks components ready to ship. Hard to find, obsolete and highly allocated integrated circuits and semiconductors are all can be found by us.
Mega Source Electronics has established a well-developed logistics system and global logistics network, which can guarantee our service very quick, convenient and efficient.
Tag:
EPM7128SQC100-15N EPM7128SQC100-10N EPM7128SQC100-15F
