USED CATERPILLAR WHEELED LOADER 966F IN VERY GOOD WORKING CONDITION
- 10 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | Caterpillar | Place of Origin: | China | Model Number: | 966F |
Product Description
1. Dimensions
A. LENGTH WITH BUCKET ON GROUND: 8366 mm
B. WIDTH OVER TIRES: 2935 mm
C. HEIGHT TO TOP OF CAB: 3585 mm
D. WHEELBASE: 3350 mm
E. GROUND CLEARANCE: 476 mm
F. HINGE PIN - MAX HEIGHT: 4118 mm
H. REACH AT MAX LIFT AND DUMP: 1398 mm
2. Engine
MAKE: Caterpillar
MODEL: 3306
NET POWER: 220 hp 164.1 kw
GROSS POWER: 235 hp 175.2 kw
POWER MEASURED @: 2200 rpm
DISPLACEMENT: 10.5 L
NUMBER OF CYLINDERS: 6
ASPIRATION: Turbocharged
3. Operational
OPERATING WEIGHT: 20485 kg
FUEL CAPACITY: 304 L
HYDRAUILC SYSTEM FLUID CAPACITY: 205 L
ENGINE OIL FLUID CAPACITY: 28 L
COOLING SYSTEM FLUID CAPACITY: 41 L
TRANSMISSION FLUID CAPACITY: 59 L
FRONT AXLE/DIFF FLUID CAPACITY: 47 L
REAR AXLE/DIFF FLUID CAPACITY: 47 L
STATIC TIPPING WEIGHT: 13982 kg
TURNING RADIUS: 6779 mm
OPERATING VOLTAGE: 24 V
ALTERNATOR SUPPLIED AMPERAGE: 50 amps
REAR AXLE OSCILLATION: 26 degrees
TIRE SIZE: 26.5-25 14PR
4. Transmission
TYPE: Planetary powershift
NUMBER OF FORWARD GEARS: 4
NUMBER OF REVERSE GEARS: 4
MAX SPEED - FORWARD: 37.6 km/h
MAX SPEED - REVERSE: 42.6 km/h
5. Hydraulic System
RELIEF VALVE PRESSURE: 20684.3 kPa
PUMP FLOW CAPACITY: 302 L/min
RAISE TIME: 7.1 sec
DUMP TIME: 2 sec
LOWER TIME: 2.4 sec
6. Bucket
BREAKOUT FORCE: 215.5 kN
DUMP CLEARANCE AT MAX RAISE: 2845 mm
BUCKET WIDTH: 3107 mm
BUCKET CAPACITY - HEAPED: 3.6 m3
BUCKET CAPACITY - STRUCK: 3.1 m3
7. PAYMENT AND SHIPMENT
In good working condition
Price: Negotiable
Locate in shanghai,China
Package: In bulk or by container
Deliver in 1-7 days after confirmation
Payment:T/T 30% deposite ,70% before loading
8.AFTER-SALE SERVICE & WARM TIPS
(1)、We can arrange all for the shipment if you need once we made a deal.
(2)、We have a very professional team to solve all problems or buy some quick-wear parts for you before loading.
(3)、All photos and datas of products revealed here is based on truth of machines.
(4)、All machines are imported by normal way with complete procedures.
Should you have any other question, Please feel free to contact us.
