GUJ30 mine sensor for pile of coal mine intrinsically safe electrical equipment, suitable for coal mine gas and coal dust explosion dangerous environment. With KHP128 Z type coal mine belt conveyor comprehensive protection device, used for belt conveyor of coal detection and protection.
performance characteristics
This sensor is a mechanic. CAM mechanism is adopted and torque amplification principle of omnidirectional, action quick, can in dry coal, water, coal and water spray to work normally. When there is a conveyor buried the nose, full, full of coal hopper, coal coal hit a contact position transducer and facilitate touch rod swinging Angle of deviation between the center line of action more than 30 ° plus or minus 3 °, sensors, this sensor can automatically cut off the voltage is implemented coal conveyor protection.
Technical parameters
Type：GUJ30； Explosion-proof type：ExibⅠ；
Contact resistance,：≤0.1Ω； Contact capacity：DC12V/0.5A；
Action point：30°±3°； Reset the Angle：15°±3°；
Sheath maerial of rotation Angle limit value：≤70°；
Touch the lever action force：5N～9N；
Overall dimensions：380170×72mm；
weight：3kg；
