Corner Connector Cutting Machinery for Aluminum Profile

Corner Connector Cutting Machinery for Aluminum Profile thumbnail-1
Corner Connector Cutting Machinery for Aluminum Profile thumbnail-2
Corner Connector Cutting Machinery for Aluminum Profile thumbnail-3
Corner Connector Cutting Machinery for Aluminum Profile photo-1
Corner Connector Cutting Machinery for Aluminum Profile photo-2
Corner Connector Cutting Machinery for Aluminum Profile photo-3
US$ 2100 - 2100 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Tenma
Place of Origin:
China
Model Number:
Contact Supplier Request Quote Chat Now
Jinan Tenma Machinery Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Tenma
Place of Origin China

  corner connector cutting machinery for Aluminum profile













 Company introduction :





Jinan Tenma Machinery Co., Ltd. serves for architectural windows and doors industry and architectural glass industry, specializing in manufacturing complete sets of architectural energy-saving plastic windows and doors machines, aluminum-alloy windows and doors machines, insulating glass machines, and curtain wall machines.





1. Description;





  1. The machine is used for cutting aluminium corner anncecter for aluminium window and door

  2. Linear bearing motion pair gave less resistance force and ensure high processing accuracy.

  3. Adopting automatic feeding system for the feeding device, it is with features of stability and reliability, and high efficiency.

  4. Clamping and feeding process adopt pneumatic control; It is with features of convenient operation, reliability, and productio efficiency.

  5. Once clamping can achieve continues cutting of 6 corner profile

  6. Control system with automatic counting function.

  7. The cutting length numbers will be saved automatically when cutting off electricity







2. Technical Parameter:



Power Supply 380V 50Hz
Cutting Motor Power 3kw
Motor Rotary Speed 2840r/min
Operation Air Pressure 0.5-0.8mpa
Auto-feeding Length 5-580mm
Air Consumption 80l/min
Cutting Length no limit when selected manual mode
Cutting Speed 0-3m/min
Blade Specification Ø500*Ø30*4.4 mm
Blade W&H 140*140mm
Cutting Profile Surface Plane ≤0.10mm
Cutting Surface Verticality 0.1mm
Cutting Surface Roughness Ra12.5μm
Outside Dimension 5670*1770*1840mm
Weight 500kg
