Environmentally Friendly UV Inkjet Printer Windows 7 / High Resokution 1440DPI

Type: inkjet printer

Brand Name: A-Starjet

Place of Origin: Changzhou

Automatic Grade: Automatic

Usage: digital UV printer

Certification: CE

Voltage: AC 100-220V

Model: 7702 UV

Weight: 385 kgs

Color:  CMYK

Keyword: UV printer

After-sales Service: Yes

Item

A- Starjet 7702 UV

Print head

Two DX7 print heads

Number of nozzles

1440 nozzles per head

Color

4 Colors:Cyan,Magenta,Yellow,Black

Resolution

1440dpi(max)

Height of print head

2～5mm

Size of ink droplet

1.5～21pl

Printing width

1700mm

Speed

3pass  30.0sq.m per hour

4pass   22sq.m per hour

6pass   14.7sq.m per hour

8pass   11.0sq.m per hour

Media width

1900mm

Media take up

Yes

Media feeder

Option

Media payload

70kgs

Heating system

Print heater and Post heater with PID temperature control temperature range:room temperature to 80℃

Ink

CMYK White/Grossy Ink(Special color)

Ink cartridge

8×350ML continuous ink supply, Optional bulk system

Rip software

iPrint3.0 16bit(Optional Photoprint,Wasatch)

Control software

Print console

Operation system

MS Windows XP ﹠ Windows 7

Interface

USB port ver2.0

Power voltage

AC 220～240V 50～60Hz or AC 110～120V 50～60Hz

Printing environment

Temperature:20～25℃,humidity:40-60%

Printer dimension

W2840×D900×H1250mm

Packing dimension

W2920×D930×H730mm

Net weight

245kgs

Gross weight

385kgs
