Home > Products > Outdoor Full Color LED Display > Advertisment IP65 Outdoor Full Color Led Display , P16.1 Led Board
Advertisment IP65 Outdoor Full Color Led Display , P16.1 Led Board
- T/T L/C D/P D/A
- 7 days
You May Like
-
P12 HD Outdoor Full Color Led Display Panel For Postal Offices
-
H110/ V70 Outdoor Full Color LED Display FOR Commercial Advertisement
-
IP 65 Outdoor Full Color LED Display , Shopping Malls Led Signs
-
2R1G1B P25 Outdoor Full Color LED Display With Refresh Rate 480 Hz
-
Shopping Malls P20 Outdoor Led Display , Driving IC MBI 5024 / 5041 LED Panel
-
P16.3 Outdoor Full Color LED Display , Modules Size 320 (L) mm * 320(H) mm
Product Details
| Brand Name | LED-HERO | Place of Origin | China | |
Product Description
Certification:CE, RoHS, UL, EMC, ISo9001
P16.1 Advertisment IP65 Outdoor Full Color Led Display , 2R1G1B led board
Quick Detail:
1. Relatively low cost;
2. Stable capability;
3. High brightness;
4. Good after-sale service.
5. Waterproof IP65.
6. Three years warranty
Description:
1. High definition can display the picture clearly.
2. High brightness. The brightness can up to 6500 cd/㎡, if the direction is face to the sun, you still can see the images on the screen.
3. No mosaic due to excellent flatness and nice uniformity of light-emitting,making the images softer and vivider.
4. Supports brightness adjustment and white balance custom adjustment with 256 levels, which enables mix usage of different batches of display.
5. High stability and long span.
Applications:
Widely used in sports stadiums, commercial applications, banking, securities, postal services, terminals, shopping malls, railway stations, postal services, telecommunications, institutions, monitoring, schools, restaurants, hotels, entertainment, businesses and other places of different outdoor advertising.
Specifications:
| Specification | P16 |
| Item 1 ---LED Chip | |
| Brand | Epistar ,Opto , Cree , Nichia |
| Country of Origin | Taiwan. United States. Japan |
| Span life | ≥ 100,000 Hrs |
| Item 2--- Modules | |
| Pixel Pitch | PH 16 |
| LED configuration | DIP 546 |
| LED Composition | 2R1G1B |
| Modules size | 256 (L) mm * 256 (H) mm |
| Driving IC | MBI 5024/5041 |
| Driving Method | Constant Current / (Static) |
| Item 3--- Cabinet | |
| Cabinet size | 1024 (L) mm * 768 (H) mm |
| Cabinet Material | Steel / Aluminum |
| Installation Method | Fix / Hanging / Rental |
| Cabinet weight | |
| Item 4--- Display screen | |
| Brightness | ≥ 8000cd/㎡ |
| Viewing Angle | H110°/ V70° |
| Refresh Rate | ≥800 Hz |
| Fresh Requency | ≥60Hz |
| Input Voltage | AC220V/50Hz or AC110V/60Hz |
| Power Consumption | Max.:1070 W/㎡ Average:440W/㎡ |
| Front and Back protective Grade | IP65/IP43 |
| Signal Output | HDMI DVI VGA RGBHV PbPr (HDTV) |
| Signal Connection | Video TB SDI |
| Controlling System | Linsn/ Colorlight / Nova/ DB Start … |
| Operating System | Windows98/me/2000/NT/XP Window7 ,Vistar |
Competitive Advantage:
1.The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.
2.High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3. High refreshing rate enables high resolution photo and video be made by camera.
4. Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.
5. After sales service and technical support are available around the clock.
