Help CenterP 10 Billboard Rental Led Screen Flexible Silan / Cree / Nichia Led Chip for Park
Related Products
-
High Definition Full Color Outdoor Rental Led Display p6 SMD 600Hz With Haging InstallationNegotiableMOQ: 1 Kilogram -
High Resolution 10mm RGB Led Screen RentalNegotiableMOQ: 1 Piece
-
Flexible P3 Rental Led Screen 6500K - 9500KNegotiableMOQ: 1 Piece
-
High Definition 1R1G1B P8 Rental Led ScreenNegotiableMOQ: 1 Piece
-
Electronic Thin High Resolution Outdoor Led Screen Rental P10 360HZ for AdvertisingNegotiableMOQ: 1 Piece
1.High pixel density.
2.Steady performance.
3.Fresh&beautiful images.
4.CE,RoHS,FCC.
Technical parameter:
|
Pitch size |
10mm |
|
Pixel configuration |
1Red,1Green,1Blue,DIP |
|
Cabinet solution(W*H) |
16dots*16dots |
|
Pixel density |
10000dots/sqm |
|
Cabinet size(W*H) |
160mm*160mm |
|
Brightness(average) |
≥6000cd/ sqm |
|
View angle(H/V) |
H/V 120/60degree |
|
Power consumption |
100W/sqm~1200W/sqm |
|
Net weight |
<65kg/sqm |
|
Voltage |
220V/110V±15% 50Hz |
|
Color scale |
256~65536degree /1.07 billion colors |
|
Display mode |
VGA640X480—VGA1600X1024 |
|
Life span |
≥100,000hours |
|
Refresh frame frequency |
≥360HZ |
|
Exchange frame speed |
>150frames per second |
|
Control distance |
≤100M (Cat.5 without repeater) /500M(multi-mode optical fiber)/20000m(single-mode optical fiber) |
|
Operating temperature |
-25°C~+60°C |
|
Operating humidity |
10%—95%RH |
|
Software |
LEDstudio |
|
Best view distance |
3--150m |
|
Communication port |
VGA |
|
Control mode |
Synchronous, real time with PC |
|
Drive mode |
Constant current driving |
|
Protection of power supply |
overtemperature, overcurrent, overvoltage etc. |
|
Operating system |
Windows98/Me/2000/Xp |
|
Brigtness adjustment |
100 levels automatically or by hand |
