CE Certification Thermo Conductive Hot Oil Temperature Control Unit , 300 Degree

Delivery Time:Within 20days after receiving deposit
Certification:CE|ISO

CE Certification Thermo conductive Hot Oil Temperature Control Unit , 300 Degree

Quick Detail:

1. Explosion-proof equipment(optional)

2. Shutdown immediate cooling function(optional)

3. Certification:CE & ISO

4. Pump power: 2.2KW

5. Inlet water temperature:25℃-300℃

6. Alarm function:pump reversal,Oil shortage, overheating, overload and oil overflow

7. Warranty:1 year

Description:

Explosion-proof equipment (optional) Air blowing and return oil return function(optional) Thermometer for return oil Automatic air-exhausting function after startup Switchover of heating power Negative-pressure system(optional) RS485 communication function for automated management(optional) Shutdown delayed cooling function(optional) Isolated electric box for longer services lives of electric appliances BY-PASS pressure release loop for hot oil Customizable multi-point temperature control unit Customizable horsepower and heating power of oil pump Brands OMRON, FUJI, TE. LS. MOELLER, ABB, WEST for electric appliance Range of temperature control:+25℃-300℃ for incoming water CE certificate Stainless steel integrated pipelines for less pipe resistance and rust Control mode: imported microcomputer or PLC(optional) Perfect safety protection, fault display, easy repair and maintenance even free of professionals

Specifications:

ITEM	UNIT	AEOT-30
Temp control range	℃	Inter water temperature +25℃-300℃
Temp control accuracy	℃	PID±1℃
Power supply		AC3∮380V(3phase+Earth)
Heat transfer medium		Thermo conductive oil
Cooling method		Indirect cooling
Expansion tank capacity	L	38
Heating capacity	KW	30/36
Pump power	KW	2.2
Pump flow	M3/h	10
Pump pressure	Kg/cm3	2.8
Maximum power consumption	KW	38.5
Alarm function		Pump reversal/Oil shortage/Overheating/Overload/Oil overflow
Cooling water pipe	inch	1/2
Circulating water pipe	inch	1
Size(L×W×H)	mm	1350×500×1150
Remark:1. Tank volume in bracket is on behalf of external fuel tank volume 2. The pump pressure value in bracket matches the above pump flow in bracket

Competitive Advantage:

Strict quality control system We have the production certification organic heat transfer material heater High density heat insulation cotton and aluminum foil Our product is environmental and energy-saving Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST Imported microcomputer or PLC Customization thick copper pipe 1.0-1.2

Applications:

Aluminium Alloy: Car accessories

Magnesium alloy: Communication device, navigation

Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating Presses,M
