1R1G1B SMD 3 In 1 HD Advertising High Definition LED Display , P2 / P2.5 / P3

Delivery Time:15-35days
Certification:CE,UL, ROHS, 3C, ISO,FCC

Quick Detail:

1. Long-time stability；
2. Waterproof and dustproof；
3. Energy Saving;
4. Low power consumption.

Description:

1. High brightness which is adjustable to sufficiently meet the needs of various application environments;
2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being anti-UV, waterproof, anticorrosion and antirust;
3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture. Five-Guard Lacquer will be used for special requirements;
4. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof;
5. Display even after long-term use of perfect quality reproduction and enough brightness and white balance.


Applications:

Shopping malls
Supermarkets
Shopping centers
Public square
Super market


Specifications:LED Specification:

Part Number	SungreenLED-P2.5
Resolution	64(H)×48(V)
Pixel Pitch	2.5mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	155,000 pixels/ ㎡
Module Size	163*122mm
Driving IC	MBI5024
Driving Method	1/16 Scan, Constant Current
Screen Weight	42kg/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	2,000cd/ ㎡
View Angle	140°/140°
Gray Scale	8bits input, correction with 16 bits
Display COLOR	16.7M
Brightness Adjustment	0～100%
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	800W/ ㎡
Average Power Consumption	400W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
Operating Life	100,000hours
MTBF	5000hours
Protection Level	～
Out of Control Rate	<0.02%

Competitive Advantage:

1. High quality and low price;
2. Low consumption;
3. High brightness and resolution;
4. Perfect service available.


Tag: SMD 3 in 1 P2/P2.5/P3 HD indoor led display, P2/P2.5/P3 SMD 3 in 1 advertising led display, HD P2/P2.5/P3 led display , High-precision full color advertising P2/P2.5/P3 Led display
