Concrete Water Cooling Tower with Low Noise for Industrial Cooling
Description:
The uniformity of water distribution and the lower resistance of air are adequately considered while designing of the cross-section of beam and column to assure the strength and stability of tower.
The concrete structure with longer span is used for the cooling tower frame structure. The structure including enclosure casing, fan deck and partitions shall be of concrete structure.
Safe Access: Each tower is equipped with one stairway at one end and one ladder at the other end so as to assure the convenience for normal maintenance of the cooling tower. Clean Appearance: A special water-discharge design on the fan deck, instead of free drainage design, is applied to discharge the rainfall so as to prevent the exterior wall from dirty and to keep the surface wall clean. Harmonious Color of Construction: The appearance color of cooling tower applies the slivery white color or other colors so as to keep it harmonization with environment. The specified color by owner is available.Quick Detail:
The type cooling tower is an advanced product summing up of many years’ experience of designing and manufacturing cooling tower, special in large-scale field erection cooling tower, and combining the newest technology of the cooling tower industry at home and abroad.
Specifications:
|
Model |
Waterflow per cell (m3/h) |
Dimension |
Mechanical equipment |
||||
|
L(mm) |
W(mm) |
H(mm) |
Fan Dia. (mm) |
Airflow(m3/h) |
Motor(KW) |
||
|
CNTC-750 |
750 |
7000 |
7000 |
8600 |
5000 |
464000 |
30 |
|
Design condition: The inlet temp. and outlet. Temp. is 43℃ and 33 ℃; The WBT is 28℃; SS is less than 50 ppm. |
Applications:
This type cooling tower could be widely used in the recycling water system in such fields as Metallurgy, Electric, Chemical and Machinery industry and so on.
Competitive Advantage:
Non-metalizing of the components Streamlining of air-flow field Low energy-consumption of operation Super low loss of drift High-qualified draught device
