Help CenterAutomatic Hydraulic Single Hook Tire Bead Remover For Remove Bead Wires
Related Products
-
SG Double Hook Tire Bead Remover For Passenger Tire Bead Wires , 60-120 Pcs/hrNegotiableMOQ: 1 Set -
SL Automatic Double Hook Tire Bead Remover , 11+11Kw 15+15Tons Pulling ForceNegotiableMOQ: 1 Piece
-
Automatic Double Hook Debeader Tire Bead Remover 15+15Tons Pulling ForceNegotiableMOQ: 1 Set
-
11Kw Hydraulic Single Hook Tire Bead Remover For Remove Bead WiresNegotiableMOQ: 1 Set
-
6.5T Double Hook Tire Bead Remover For Passenger Tire Bead Wires 60-120 Pcs/hrNegotiableMOQ: 1 Piece
Certification:ISO9001, CE
Power: 11Kw Cylinder moving:1200mm Tyre size:≤1200mm diameter Pulling force:13Tons Capacity:10-20 pcs/hr Dimension:3150*760*1120mm Weight: 1200kg
It is specially designed for remove the bead wires. Hydraulic!
Description:
This machine consist of motor ,hydraulic system,drawing hook,drawing mouth,and main part,etc. Its basic principle is driven hydraulic system and made the cylinder work by the motor to make the drawing hook liked the cylinders pull pole reciprocate motion.put the tire on the drawing month and jut the drawing mouth to hook steel wire. meanwhile the rubber part of tire is teared because of the drawing mouth block it.thus get the effect of separating smoothly.
Applications:
Draw out the steel wires from the tire bead.
Specifications:
|
Power |
11Kw |
|
Cylinder moving |
1200mm |
|
Tyre size |
≤1200mm diameter |
|
Pulling force |
13Tons |
|
Capacity |
10-20 pcs/hr |
|
Dimension |
3150*760*1120mm |
|
Weight |
1200kg |
Competitive Advantage:
1. Hydraulic Driving
2. Easy Operation
3. adopt international advanced plunger pump technology,low noise,and high pressure and improved the stability and life
Tag: Tire wire drawer, bead wire puller, tire debeader
