Certification:CE RoHs FCC
Quick Detail:
○ 9 years production experience in power supply.
○ 3 senior engineers with over 15 years experience in this field
○ Low power consumption, high reliability
○ Protections: Short circuit/Over load/Over voltage
○ 100% full loading burn-in test
○ All products have been checked and packaged in good condition before dispatch
Description:
35W 5V 7A POWER SUPPLY
Universal AC Input (full range)
Dimension: 85*60*33.5mm (L\'W\'H\')
Cooling by free air convection
Applications:
1, Digital and electronic products
2, Fiber transceivers, game player, LED, CCTV camera;
3, Electrical Equipment, Instrumentation
4.Industrail Equipment
5, Communications and security products;
6.LED Strip Lighting/ LED lamp / LED Lights
7.LED Display,etc.
Specifications:
|
Model number |
HT-35-5 |
|
|
Input |
Input voltage |
AC90-264V, 50/60Hz |
|
Output |
Max power |
35W |
|
Output voltage |
DC 5V + / - 5% |
|
|
Ripple wave |
(mVp-p): <10% |
|
|
Temperature coefficient |
±0.02%/°C |
|
|
Setup rise hold up time |
200s 100s 30s |
|
|
Protection |
Overload protection |
105%-150%vA,automatic recovery |
|
Short-circuit protection |
Once short-circuit protection, automatic recovery |
|
|
Over-voltage protection |
115~135% |
|
|
Insulation |
Withstand Voltage |
Input and output internal1.5KVAC,Input and enclosure1.5KVAC,Output and enclosure0.5KVAC |
|
Isolation resistance |
Input and output internal: Input and enclosure, Output and enclosure500VDC/100MΩ |
|
|
Environment |
Working temperature |
0°C-40°C,10%-90%RH |
|
Store temperature |
-10°C~ +60°C,10%-90%RH |
|
|
Size |
Size |
85*60*33.5mm |
|
Net weight |
145g |
Competitive Advantage:
1. Factory direct sales: Wholesale discounts & good quality
2. Timely delivery : 1-7 business days (depends on quantity)
3. OEM and ODM Service.
4. Certification: Our products are mostly certified by CE, LVD, RoHs, EMC, FCC
5. Good service: Your inquiry related to our products or prices will be replied in 24hours. Well-trained and experienced staffs to answer all your enquires in fluent English
Tag: LED power supply, Switching power supply, Constant Voltage Power Supply
