I. Use
1. Used for the second stage separation equipment of the solid control system which is used in drilling and horizontal wells.
2. Used for solid liquid separation project of various mining areas.
3. Used for chemical and food processing project.
4. Used for other solid liquid separation project and environmental protection system.
II. Characteristics
1. Various type of cleaner for choosing such as big process load desander, big process load desilter and integral desander and desilter.
2. Use balanced elliptical motion trace for sieving, equip fast installed screen device, variable frequency device and anti-splash device.
3. Various screen box dip angle adjustment such as manual, electo-hydraulic and hydraulic.
4. Over 300 meshes can be installed through variable device for finer screening.
5. Variable frequency system can be used to improve delivery capacity of solid phase and screening capacity of liquid phase. Solid phase delivery can reach 100t/h.
|
RSD/YTS300*2-100*16 |
RSD/YTS300*4 |
RSD/YTS100*26 |
||
|
Nominal diameter of hydrocyclone (mm) |
φ100 |
φ300 |
φ300 |
φ100 |
|
Number of Hydrocyclone (P) |
16 |
2 |
4 |
26 |
|
Capacity (m3/h) |
200~240 |
200~280 |
300~360 |
300~360 |
|
Separation (μm) |
20~100 |
50~150 |
50~150 |
20~50 |
|
Sand pump power (Kw) |
≥55Kw×2 |
≥75Kw |
≥75Kw |
|
|
Operating pressure (MPa) |
0.25~0.35(recommend 0.2) |
0.25~0.35(recommend 0.2) |
0.25~0.35(recommend 0.2) |
|
|
Shaker type |
RSD2005-P |
RSD2005-P |
RSD2005-P |
