MTA-600-D Coil Winding Magnetic Wire Tensioner With 80 - 600g
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom Magnetic Wire Tensioner With 5m/s , 3 - 30 G.f MT-30
-
5m / s Magnetic Wire Tensioner For Winding Machine MT-400
-
MT - 400 Magnet Wire Tensioner With 50 - 400g Tension Scope
-
MTA-600-D Coil Winding Machine Magnetic Wire Tensioner With Cylinder
-
Coil Winding Magnetic Wire Tensioner With 0.04 - 0.12 mm MT-100
-
MT-30 Coil Winding Mechanical Wire Tensioner For Tension Control
Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
Product Description
magnet tensioner for coil winding machine magnet tension unit for TANAC winding machine wire tensioner magnetic wire tensioner
MTA-600-D Coil Winding Magnetic Wire Tensioner With 80 - 600g
|
Place of Origin: |
Dong Guan China |
|
Brand Name: |
KIMCHEN |
|
Model: |
MTA-D Series |
|
Feature: |
With Cylinder |
|
Tension test condition: |
Wire speeding 5m/s refer roundness Bobbin |
|
Application: |
Winding machine |
|
Function: |
Tension Control |
|
Suit: |
Winding of big tension |
|
Product Size: |
170mm*160mm*60mm |
|
Weight: |
1.20 KG |
Detailed Product Description:
MTA Series Magnetic Tensioner with Cylinder by using permanent magnet,tension is generated to the damp wheel.The non-contact mechanism design provides stable,consistence and precision tension to the wire. Excellence for both high and normal speed winding.
MTA-D Magnetic Tensioner Specifications:
|
Model |
Applied wire diamiter(mm) |
Tension scope(g) |
|
MTA-600-D |
φ0.12-φ0.35 |
80-600 |
|
MTA-800-D |
φ0.14-φ0.40 |
100-800 |
|
MTA-1200-D |
φ0.20-φ0.50 |
200-1200 |
