HD P16 Outdoor Led Display Screen Full Color With -20℃~+50℃
Quick Detail:
Working temperature : -20℃~+50℃ Module size(MM) : 256*256 Advertising media, sports stadiums, airport station, business establishments, and public square BVO-16 outdoor full color LED display/LED screen is suitable for commercial and advertising display with advantages of less power consumption, high brightness, High resolution, and long lifetime.Description:
BVO series ultra low power outdoor LED display or LED screen are new products with XIWAN new technology. Xiwan have invested millions of dollars on this new technology. Dedicate to save energy cost for big LED display and improve image quality very effectively. We have now developed P10, P12, P16, P20 and P25, you can choose according to your own applications.
Qualified LED core from Epistars, Silan and other big brand.
Qualified LED driving from Meanwell
Applications:
Advertising media, sports stadiums, airport station, business establishments, and public square
Specifications:
|
Item No. |
BVO-P16 |
|
Pixel Pitch(MM) |
P16 |
|
Module resolution |
16*16 |
|
Module size(MM) |
256*256 |
|
Pixel combination |
DIP 1R1G1B1W |
|
Pixel density |
3906 pixels/㎡ |
|
Driving way |
Static |
|
Cabinet size(MM) |
1024*1024 |
|
Cabinet resolution |
64*64 |
|
Cabinet pixel |
4096 |
|
The number of modules |
16 |
|
Cabinet type |
Fixed installation water proof iron box |
|
Cabinet weight (Kg) |
60 |
|
Average Power Consumption (W/㎡) |
≤150W/㎡ |
|
The maximum power(W/㎡) |
≤310W/㎡ |
|
Brightness (Cd/㎡) |
9800 |
|
Gray scale |
16bit(4096 levels) |
|
Refresh rate |
≥800 |
|
Brightness adjustment |
256 levels |
|
Frame frequency |
60HZ |
|
Input voltage |
110~220VAC |
|
Working temperature |
-20℃~+50℃ |
|
Work humidity |
10%-90%RH |
|
Best stadia |
≥12m |
|
The whole screen perspective |
H:135°;V:55° |
|
IP rating |
Front:IP65;Back:IP54 |
|
MTBF(hrs) |
1000 |
|
Life span(hrs) |
100000 |
Competitive Advantage:
5 advantages of XIWAN BVO series of low power consumption product:
●50% energy savings
Up to 50% reduction in energy consumption, in special circumstances, even more than 70%, it reduced the use-cost greatly.
Take BVO-20 LED display as example, compared with ordinary products, a 100m2 screen works 24 hours per day, 365 days per year, it can save energy =(160W×100m2×24h×365)/1000 =140,160KW (KWH), reducing greenhouse gas emissions 106,241kg
●30% higher brightness
Increased 30% max brightness, more than 12,000cd of the brightness cou
