Counter Flow Cooling Tower Fill, Cooling Tower Filler, PVC Fill

Cooling tower fill 1000x500mm
Cooling tower filler specifications:
1. Marly PVC fills, Size: 1220*300mm, 1220*600mm
2.Use Temperature: 50-68C
3.Absorption rate: < 0.015%
4.Drift water loss rate:<0.001%
PVC Cooling Tower filter Filling Technical Data:
Surface area: 45ft2/ft3(157.5m2/m3)
SHEET SPACING:19 mm
Flute angle: 30°
Sheets per ft.: 16
media pack sizes(Depth, Width, Length):
Minimum: D12 in(305mm), W 6 in(153mm),
L: 1 ft (305mm) Maximum: D24 in(610mm), W 24 in(610mm),
L: 10 ft (3050mm) Standard: D12 in(305mm) or 24 in(610mm), W 12 in(305mm) or 24 in(610mm),
L: 4 ft (1220mm), 6 ft(1829mm), 8 ft(2439mm) or 10 ft(3048mm)
fill pack for cooling tower media and type:
1).\\\\"T\\\\" type wave fill Sheet spacing: 33mm
Weight: 15.4kg/ m3 (after deformed)
Thickness after forming:15mils
Sheet size: 500mm×2400mm/ 500mm×2000mm/ 500mm×1200mm
2).\\\\"S\\\\" type wave fill
Sheet Spacing:31mm
Weight: 17.6kg/ m3 (after deformed)
Thickness after forming:15mils
Sheet size: 500mm×1000mm
3).\\\\"TS\\\\" fill
Sheet spacing:18.9mm
Weight: 20.776kg/ m3 (after deformed)
Thickness after forming:10mils
Sheet size: 500mm×2400mm/ 500mm×2000mm/ 500mm×1000mm
4).\\\\"HS\\\\" fill
Sheet spacing:20mm
Weight: 18.83kg/ m3 (after deformed)
Thickness after forming:10mils
Sheet size: 304mm×2400mm/ 304mm×2000mm/ 304mm×1200mm/ 304mm×1000mm.
Cooling tower infill characteristic:
This kind of cooling tower fill with the advanced technical, long lifetime, low resistance, light weight. During the service, the fill can increase the water flow process. It is widely used in Square cooling tower.
1) Application: put into the square cooling tower
2) Characters: acidproof, alkali-resisting, anticorrosion for the organic solvent good performance of inflaming retarding oxygen index≥31
3) Description: Normal Size:500mmX1000mm OR Width: Meet your demand Length: Meet your requirement. Thickness: Meet your demand
4) Working temperature: PVC: -20°C~70°C
Cooling Tower filter have the advantage as below:
1. Anti-aging
2.Excellent Performance
3.Long Service life
4.Good heat exchange perfomance, and excellent Cooling efficiency
5.Easy to install Cooling tower fill media is the most important part of the cooling tower, its efficiency high and low which depends on the cooling water and air in the packing of the extent of the full access.
