Home > Products > Gearless Traction Machine > 200m Double Wrap Gearless Traction Machine ,Traction Ratio 1:1 2:1 WTYF328
200m Double Wrap Gearless Traction Machine ,Traction Ratio 1:1 2:1 WTYF328
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
120m Permanent Magnet / Gearless Traction Machine 4000kg 3.0m/s WTYF380
-
32 Poles Gearless Traction Machine 5000kg Shaft Load , 1.75m/s WWTY
-
Gearless Traction Machine 3000kg Shaft Load , 2m/s WWTY5
-
Gearless Traction Machine 3000kg Shaft Load , 2m/s WWTY5A
-
Gearless Elevator Traction Machine 320KG, WWTY6
-
32 Poles Gearless Traction Machine 3000kg Shaft Load , 2.0m/s WWTY8（1000KG）
Product Details
| Brand Name | XINDA | Place of Origin | China | |
| Model Number | WTYF328 |
Product Description
Delivery Time:30 days
Certification:CE / ISO9001 / ISO14001
Traction ratio: 1:1,2:1
Rated capacity: 1050,1200,1350,1600, 2000kg
Rated elevator speed: 3,3.5,4m/s
Max. lifting height: 200m
Max. shaft load: 15000kg
Applicable converter: 3 phase 400V
Double Wrap Gearless Traction Machine ,Traction Ratio 1:1 , 2:1 WTYF328
Product Description
This series of permanent-magnet synchronous gearless traction machines adapts double wrap, and the housing and support structure are integrated structure. So it has compact construction, with easy installation and maintenance, it\'s can bear high radial loads. Unique external rotor design is provided, low-noise block brake is mounted on both sides of the housing and operates with high sensitivity, high efficiency and good stability.
Product Characteristics
Traction ratio: 1:1,2:1
Rated capacity: 1050,1200,1350,1600, 2000kg
Rated elevator speed: 3,3.5,4m/s
Max. lifting height: 200m
Max. shaft load: 15000kg
Applicable converter: 3 phase 400V
Brake voltage: DC200V for Brake opening, and DC100V for brake holding
Number of motor poles: 20 poles
