Triplex Pump Valve Assembly-4 Web Valve &seat

Valve& seats

The material of cross-arm seat is 20CrMnMo/20CrMnTi forging steel, carburizing and quenching, thickness is 1.5mm-1.8mm,hardness is HRC 58-62, and hardness of the core is HRC27-33 The 55 angle and screw thread of the valve have.

four-muscle valves

Valve body is forged from alloy steel 20 CrMnTi/20CrMnMo, after heat treated they can be reach HRC58-62, the valve seat cone and wing double support, Suiting To Almost All Popular Mud Pumps In The World. Valves & Seats apply in standard environment with the longest service life of more than 600 hours.

Three-muscle valve

Three-muscle valve has larger displacement than four one, two forms of rubber installing: spinning the rubber with nut and directly cover the rubber without nut and accord with API standard. And our Cross-arm Seat is high-hardness and impact-resistance: API-4#,5#,6#,7#,8#,9# is available which are fit for high pressure jetting drilling

3web valve with full open seat

Alloy casted steel forged eliminate snap ring, plate, valve insert or valve nut which is easy installation and high work performance, Which has large emissions than three muscle valves and four muscle valves.

4 web valve and full open seat

The 4web valve is classified with Welding style and innovative one part valve, each of them has their own strength ,for welding one with high performance but best price ,while one part valve is more convenience used in the drilling work sites.

Four- wing valve& full open seats

One set-

The valves body and stem-guided four wings manufactured by whole precision casting, the rubber with plate are bolt on the body,

Second set

The valve body and four-wing meet with fiction welding into a whole, strong and durable performance.

Third-set

The valve body and stem-guided four wings are directly forged into a whole, strong and long service life.

Forth set-combined valve body and seats

Valve guide bar, four claws and plate combined together and the strength is any parts can be replaced.
