Shengquan Polyester Airslide Hose/pipe With High Quality
One side permeable,good abrasion resistance and long service life all synthetic.
One side PU coated,standard colour yellow PU-coating increases the abrasion resistance and supports at the same time the air permeability of the uncoated saide.
Material:
Warp:100% polyester high tenacity fiber
Weft:100% polyester high tenacity filament.
Characteristics:
One side air permeable,other side PU-coated.Good abrasion resistance and long service life all aynthetic,lightweight and flexible,easy to coil ageing and ozone resistant-weather resistant minimum maintenance.
Cold resistant to -30°c
Heat resistant to +160°c
Applications:
Aertion of bulk powders and granular in silos and silo wagons.
Dimension:
Standard diameter 76mm other diameter on request.
Standard lengths are 30m,50m,100m.Max length up to 500m and also avilable in any other length.
Specification:
Type |
Internal Diameter(mm) |
Falt Width(mm) |
Weight(g/m) |
HP/C---1 |
58 |
92 |
180 |
HP/C---2 |
71 |
113 |
210 |
HP/C---3 |
76 |
120 |
240 |
HP/C---4 |
77 |
125 |
300 |
Type |
Air resistance in 0.2 m³/m²/h H2O mm |
High |
600---900 |
Low |
200---500 |
Standard Lengths
Meter |
30 |
50 |
100 |
Max length up to 500m and also available in any other length.
We can produce as customers special request.
