Product Details
Brand Name: | CW | Place of Origin: | China | Model Number: | 57BYG250-112 |
Product Description
Certification:CE, ISO9000, SGS
4 Wire, 6 wire, 8 wire and 24V / 36V / 48V 57BYGH stepper motor, 1.8° two Phase and 57mm nema 23 stepping motor
Description
Detailed Product Technical Date Sheet
Model |
Step Angle(°) |
Motor Length (mm) |
Rated Current (A) |
Phase Resistance (Ω) |
Phase Inductane (mH) |
Holding Torque (N.cm Min) |
Lead Wire (No.) |
57BYG450-40 |
0.9/1.8 |
41 |
2 |
1.5 |
1.4 |
3.5 |
4/6/8 |
57BYG450-50 |
0.9/1.8 |
51 |
3 |
1 |
1.5 |
7 |
4/6/8 |
57BYG250-56 |
0.9/1.8 |
56 |
1 |
1.4 |
4.5 |
6.5 |
4/6/8 |
57BYG450-56 |
0.9/1.8 |
56 |
3 |
0.9 |
1.3 |
9 |
4/6/8 |
57BYG450-76 |
0.9/1.8 |
76 |
1.5 |
5 |
1.05 |
14.8 |
4/6/8 |
57BYG450-84 |
0.9/1.8 |
84 |
3 |
1.1 |
2.5 |
16 |
4/6/8 |
57BYG450-102 |
0.9/1.8 |
102 |
3 |
1.5 |
3.1 |
23 |
4/6/8 |
57BYG450-112 |
0.9/1.8 |
112 |
3 |
1.8 |
3.8 |
25 |
4/6/8 |
Genaral Specification
Step Angle ------------------- 1.8°±5°
Temperature Rise ------------- 80℃max
Ambient Temperature -------- -20℃~+50℃
Insulation Resistance--------- 100 MΩ Min. , 500VDC
Dielectric Strength: ------------ 500VAC for 1minute
Shaft Radial Play --------------- 0.02Max. (450g-load)
Shaft Axial Play ----------------- 0.08Max. (450g-load)
Detailed Product Structure Chart
Competitive Advantage
The above are just representative products,the derivative can made according to customs demands.
