Basic Info.
|
Model NO.: |
500, 1000, 1500, 2000, 2500, 3000, 3500, 4000 |
|
Scaffolding Part Type: |
Ring Lock |
|
Lapping Form: |
Cross Ring Scaffolding |
|
Framework: |
Combined Scaffolding |
|
Supporting Mode: |
Projecting Scaffolding |
|
Material: |
Steel |
|
Erection Position: |
Internal Scaffolding |
|
Type: |
Fixed |
|
Move Method: |
Horizontal mobile Scaffolding |
|
Structural Style: |
Multi-Pole Scaffolding |
|
500,1000,1500,2000,2500,3000: |
3.2mm, 3.0mm |
|
Export Markets: |
Global |
Additional Info.
|
Packing: |
by Bundle, Suitable for Export |
|
Standard: |
500, 1000, 1500, 2000, 2500, 3000, 3500, 4000 |
|
Origin: |
China |
|
HS Code: |
73084000 |
|
Production Capacity: |
1000tons Per Month |
Product Description
2M Ring-Lock Scaffolding System consists of hot dipped galvanized steel pie and modular components that are assembled together using integral wedge connectors. ADTO ring-Lock system is a modular scaffold system which can provide major saving in labor cost while meeting the demands for safety, ease of handling and reductions in maintenance.
Components:
Ring-Lock Standard With Spigot, Ring-Lock Ledger, Ring-Lock Diagonal, Wedge Pin, Base Collar, Steel Plank, Steel Stair Case.
Feature:
-Time efficient during assembly and dismantling
-Safe and simple one-man assembly
-No loose parts
-Maintenance free
RINGLOCK STANDARD WITH SPIGOT
(48.3mm x 3.2mm, Q345, Hot Dipped Galvanized)
DescriptionWeight/ length
Ring-Lock Standard 500mm2.76kg
Ring-Lock Standard 1000mm5.18kg
Ring-Lock Standard 1500mm7.61kg
Ring-Lock Standard 2000mm10.03kg
Ring-Lock Standard 2500mm12.45kg
Ring-Lock Standard 3000mm14.87kg
Ring-Lock Standard 4000mm19.72kg
RINGLOCK LEDGER
(48.3mm x 3.0mm, Q235, Hot Dipped Galvanized)
DescriptionWeight/ length
Ring-Lock Ledger 1000mm4.62kg
Ring-Lock Ledger 1500mm6.50kg
Ring-Lock Ledger 2000mm8.38kg
Ring-Lock Ledger 2500mm10.27kg
Ring-Lock Ledger 3000mm12.16kg
RINGLOCK DIAGONAL
(48.3mm x 3.2mm, Q235, Hot Dipped Galvanized)
DescriptionWeight/ length
Ring-Lock Diagonal 1000x2000mm10.06kg
Ring-Lock Diagonal 1500x2000mm10.95kg
Ring-Lock Diagonal 2000x2000mm12.13kg
Ring-Lock Diagonal 2500x2000mm13.50kg
Ring-Lock Diagonal 3000x2000mm15.01kg
