Ceramic Base UHF Metal Tag Complaints With EPC C1G2 (RCC6001) Specifications
Metal Tag(RCC6001)
Material: Ceramic
Dimensions: 28×28×3mm
Protocol: EPC C1G2 (ISO18000-6C)
Frequency: 860～960MHz
Chip: ALIEN HIGGS 3 (optional)
Introduction:
This tag is designed on ceramic base material. It solves the problem that tags can not be attached to metal surface(Reading distance even will be father when it is attached to metal surface). At the same time, it can work outside in the hard environment. It complaints with EPC C1G2 (ISO18000-6C), operating frequency is 860～960MHz (It can be used worldwide). Each tag has a unique ID and stores user data.
Image:
Physical Features:
Product Model: RCC6001
Material: Ceramic
Dimensions: 28×28×3mm
Weight: 7.5g
Color: Gray
Working Temperature: -40℃～150℃
RFID Features:
Protocol: EPC C1G2 (ISO18000-6C)
Frequency: 860～960MHz
Chip: ALIEN HIGGS 3 (optional)
EPC Memory: 96 bits, max 480 bits
User Memory: 512 bits
Read Range: Stationary reader: Over 4m (30dBm)
Handheld reader: Over 1.8m (28dBm)
Other Features:
Environmental: ROHS compliant
Data storage: >10 years
Re-write: 100,000 times
Fixture: 3M adhesive
Customization: Company logo print
Application: Assets statistics management, gas container management, small equipment management, warehouse logistics management, industrial manufacturing, etc.
