PURROS® Electro Pneumatic Drilling Units PR3P-1307 Manufacturer

Ⅰ. PURROS® Electro Pneumatic Drilling Units Parameters

Mode：PR3P-1307

No-load speed：700R/M

Drilling diameter：Aluminum：Φ12MM / Cast iron：Φ9.5MM / Steel：Φ8.5MM

Spindle stroke：80-120MM

Cutting feed stroke：0-60MM

Motor power: 0.55-0.75KW

Feed thrust：1200N

Air consumption：3-6L

Ⅱ. PURROS® Electro Pneumatic Drilling Units Characteristics

1. High-precision

Core technology of Electro Pneumatic Drilling Units is played very well, which completely strengthened the versatility of the product and thus made the high precision of Drilling Units reflected extremely.

2. High rigidity

Axial rail structure is used, which greatly improved the overall rigidity and fully guaranteed the stability of the hole machining.

3. High performance

A unique dual sealing structure and round body that is easy and convenient to be installed are available at the end of spindle, which can meet variety of holes machining requirement.

Ⅲ. Products can be equipped with Electro Pneumatic Drilling Units

1. Hydraulic damper (PURROS® Hydro Speed Regulator)

Speed can be adjusted arbitrarily from lower to higher by a hydraulic feeding speed control device.

2. Multi-axis machining head (PURROS® Multiple Spindle Heads)

Multi-axis machining head can be amounted, which can achieve high efficiency drilling and meet different requirements of machining axes and axis spacing. Extensive multi-axis machining head sizes are available in PURROS®.

3. Desktop support (PURROS® Universal Stand)

Such desktop support is suitable for any machining directions, which can fix the Drilling Units angle freely.

4. Combination machine

Automatic drilling can be realized as it can be installed to the non-standard combination machine.

5. Single desktop automatic bench drill

High-efficiency automatic drilling equipment can be formed if equipped with Electro Pneumatic Drilling Units, desktop support and circuitry system together. Only one button can finish the whole drilling work.

Our products are mainly exporting to Finland, China, Brazil, Belarus, Malaysia, Korea, United States, Italy,

Netherlands, Germany, Philippines, Australia, Mexico, Portugal, Dubai, etc
