A126B BS PN16, DIN, JIS GG25 BS4504 Flange Ball Valve / 15mm-300mm Manual Cast Iron Ball Valve
US$ 10 - 1000/
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
EVB
Place of Origin:
China
Model Number:
BV-003-A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
A126B Ball Valve / A126B Manual ISO,CE,DQS Cast Iron Ball Valve With 125LB PressureUS$ 10 - 1000 /MOQ: 1 Piece -
ANSI 50mm ANSI 125LB 125LB Grey Cast Iron Ball Valve / Stainless Steel Ball ValvesUS$ 10 - 1000 /MOQ: 1 Piece
-
150 LB WCB ANSI 16.5 16.47 Flange Cast Iron Ball Valve / Stainless Steel Ball ValveUS$ 10 - 1000 /MOQ: 1 Unit
-
ANSI B16.10, CLASS 125, 125LB ISO,CE,DQSStainless Steel 2\" -12\" Port Cast Iron Ball ValveUS$ 10 - 1000 /MOQ: 1 Piece
-
PTFE Gasket BS5351 Cast Steel Ball Valve, A216WCB JIS B2212 B2214 Flange Dimension 10K Cast Iron BalUS$ 10 - 1000 /MOQ: 1 Piece
Brand Name
EVB
Place of Origin
China
Model Number
BV-003-A
Delivery Time:30days
A126B BS PN16, DIN, JIS GG25 BS4504 Flange Ball Valve / 15mm-300mm Manual Cast Iron Ball Valve
| Application | ||||||
| 1.Design and Manufacture | JIS B2002 | |||||
| 2.Face to face | JIS B2002 Serless 6 | |||||
| 3.Flange End Dimensions | JIS B2212-1999 | |||||
| Test | ||||||
| Nomlnal pressure | 10K | |||||
| Test | Shell(Water) | 2.4Mpa | ||||
| Pressure | Seat(Air) | 0.8Mpa | ||||
| Main Parts and Materials | ||||||
| Number | Part Name | Material | ||||
| 1 | Body | Cast Iron(FC200 or FCD400) | ||||
| 2 | Bonnet | Cast Iron(FC200 or FCD400) | ||||
| 3 | Ball | Stainless steel(SUS304) | ||||
| 4 | Seat | PTFE | ||||
| 5 | Gasket | PTFE | ||||
| 6 | Stem | Stainless steel(SUS304) | ||||
| 7 | Stem Packing | PTFE | ||||
| 8 | Stop Collar | Carbon Steel | ||||
| 9 | Gland Flange | Cast Iron(FC200 or FCD400) | ||||
| 10 | Lever | Cast Iron(FC200 or FCD400) | ||||
| Main Dimensions | ||||||
| Norminal diameter | 10k | 16k | ||||
| L | C | D | L | C | D | |
| 15 | 108 | 70 | 95 | 108 | 70 | 95 |
| 20 | 117 | 75 | 100 | 117 | 75 | 100 |
| 25 | 127 | 90 | 125 | 127 | 90 | 125 |
| 32 | 140 | 100 | 135 | 140 | 100 | 135 |
| 40 | 165 | 105 | 140 | 165 | 105 | 140 |
| 50 | 178 | 120 | 155 | 178 | 120 | 155 |
| 65 | 190 | 140 | 185 | 190 | 140 | 185 |
| 80 | 203 | 150 | 210 | 203 | 160 | 200 |
| 100 | 229 | 175 | 250 | 229 | 185 | 225 |
| 150 | 394 | 240 | 280 | 394 | 260 | 305 |
| 200 | 457 | 290 | 330 | 457 | 305 | 350 |
| 250 | 553 | 355 | 400 | 553 | 380 | 430 |
