JIS-10K API 598 FC200 ISO,CE,DQS 2" -12" Port Size Flanged Cast Iron Ball Valve / Stainless Steel Ba

Everbearing Engineering Co.Limited

US$ 10 - 1000 / MOQ: 1 Piece

Key Specifications

Brand Name:

EVB

Place of Origin:

China

Model Number:

BV-031-A

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name EVB

Place of Origin China

Model Number BV-031-A

Delivery Time:30days

JIS-10K API 598 FC200 ISO,CE,DQS 2\" -12\" Port Size Flanged Cast Iron Ball Valve / Stainless Steel Ball Valves

Material:FC200
Trade Term:FOB
Certification:ISO,CE,DQS
Pressure:10k

Specification
Structre type: CAST IRON FLANGED BALL VALVE
REDUCED PORT :HANDLE LEVER
Face to face : ANSIN B16.10 CLASS 125
Test and Examination: API 598

Features
BLOW -OUT PROOF STAINLESS STEEL STEM
FULL PORT 2\" -12\" (DN50 - DN300)
SAFETY WORKING PRESSURE: 200PSI,1.6MPa

Materials
NO.	Part	Material
1	L-Body	Cast lron A216B /ASTM A536
2	R-Body	Cast lron A216B /ASTM A536
3	Ball	SS304/CF8
4	Gasket	PTFE
5	Ball Seat	PTFE
6	Packing	Graphite/PTEF
7	Bolt and Nut	A193 Gr B7/A194 Gr 2H
8	Stem	Stainless Steel
9	Gland Bush	Stainless Steel
10	Thrust washer	PTFE/NYLON
11	Handle	ASTM A536

Dimensions
Size	ID of valve	Length	OD of flange	length of lever	Height
DN50	50	178	152	305	95
DN65	64	190	178	405	105
DN80	76	203	191	405	125
DN100	100	229	229	450	180
DN125	125	254	279	550	185
DN150	152	267	279	550	185
DN200	203	292	343
DN250	254	330	406
DN300	300	356	483
