Cast Iron Rising Stem Gate Valve With FC20 Wedg, 10K FC2 Body Bronze B62 Seat Ring Cast Iron GateVa
US$ 10 - 1000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
EVB
Place of Origin:
China
Model Number:
GTV-008-S
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Socket GG50 Cast Iron Gate Valve With DI + EPDM, NBR Wedge, DN50 ~ DN300 Forged Steel Gate ValveUS$ 10 - 1000MOQ: 1 Piece -
125LB ASTM A536 65-45-12 Body Cast Iron Gate Valve, Cast Iron Rising Stem Resilient Seating Gate ValUS$ 10 - 1000MOQ: 1 Piece
-
Cast Iron Rising Stem Resilient Seating Gate Valve,125LB ASTM A536 65-45-12 Body Cast Iron GateValvUS$ 10 - 1000MOQ: 1 Piece
-
API600 A216 WCB Body ANSI Size15 ~ 500 Cast Iron GateValve With ANSI16.5 FlangeUS$ 10 - 1000MOQ: 1 Piece
-
DIN 3352 1.0619 Body Diameter 40 ~ 400 Cast Iron GateValve With A47-32510 Hand WheelUS$ 10 - 1000MOQ: 1 Piece
Brand Name
EVB
Place of Origin
China
Model Number
GTV-008-S
Delivery Time:20days
Certification:CE,ISO9001
Certification:CE,ISO9001
Cast Iron Rising Stem Gate Valve With FC20 Wedg, 10K FC2 Body Bronze B62 Seat Ring Cast Iron Gate Valve
| Application | |||||||
| 1 | Design According to JIS-10K | ||||||
| 2 | Flange End Face to JIS B2212 | ||||||
| Test | |||||||
| Working pressure | 10K | ||||||
| Shell pressure | 21.1Kg/cm2 | ||||||
| Seat pressure | 15.0Kg/cm2 | ||||||
| Main Parts and Materials | |||||||
| Number | Part Name | Material | |||||
| 1 | Body | FC2 | |||||
| 2 | Seat Ring | Bronze B62 | |||||
| 3 | Wedge | FC20 | |||||
| 4 | Wedge Ring | Bronze B62 | |||||
| 6 | Stem | AISI 420 | |||||
| 7 | Bonnet Gasket | Graphite | |||||
| 9 | Bonnet | FC20 | |||||
| 11 | Packing | Graphite | |||||
| 14 | Gland Follower | FCD45 | |||||
| 15 | Stem Nut | Brass | |||||
| Main Dimensions | |||||||
| Norminal diameter | L | D | D1 | b | n-d | DN | H(open) |
| 50 | 180 | 155 | 120.7 | 15.9 | 4-Φ19 | 50 | 375 |
| 65 | 190 | 175 | 139.5 | 17.5 | 4-Φ19 | 65 | 408 |
| 80 | 200 | 185 | 152.5 | 19.1 | 4-Φ19 | 80 | 442 |
| 100 | 230 | 210 | 190.5 | 23.9 | 8-Φ19 | 100 | 545 |
| 125 | 250 | 250 | 216 | 23.9 | 8-Φ22 | 125 | 656 |
| 150 | 270 | 280 | 241.5 | 25.4 | 8-Φ22 | 150 | 770 |
| 200 | 290 | 330 | 298.5 | 28.6 | 8-Φ22 | 200 | 959 |
| 250 | 330 | 400 | 362 | 30.2 | 12-Φ25 | 250 | 1255 |
| 300 | 350 | 445 | 432 | 31.8 | 12-Φ25 | 300 | 1443 |
