ZTS-120/120R total station
Specification:
Model No: ZTS-120/120R
Angle Measurement (Hz. V)
Measuring Method: Absolute encoding
Min display unit: 1"
Accuracy: 2"
Telescope:
Magnification: 30X
Field of view: 1° 30
Tube length: 150 mm
Cross Wire: Lighting
Auto Compensator:
System: Single axis Liquid-electric
Work range: ± 3"
Accuracy: 1"
Distance Measurement (IR)
Max distance (Good weather): 2000m/2500m
Mini Prism(60mm x 60mm): 800m
Precision: 2mm+2ppm
Measure time: Fine measurement: 1.0s, Tracking: 0.5s
Without prism measurement (RL)
Max distance: 350m
Single prism: > 7500m
Precision: 3mm+2ppm
Measure time: Tracking: 2.0s
Communication:
Internal memory: 20000 byte
Ports: 1 X RS232
File format: ASC I I
Operation:
Operate system: In-time operation system
Display: Figuration: 192 X 96, Character: 6 lines X 12 words
Keyboard: Double number board.
Laser Plummet: Accuracy: 1mm(when machine at 1.5m)
Environment:
Operating temperature range: -20 to +50
Storage temperature range: -40 to +70
Dust and water protection: IP54
Weight(including battery and base): About 5.5 KGS
Power Supply
Battery type: Ni-H battery
Voltage: DC 7.4V 3000mAh
Continues operation time: 10 hours
Measurement times: About 12000 times
Send Inquiry to This Supplier
