Outdoor PTZ Dome Camera with OSD Menu SC-SO800L Series

OSD Menu High Speed Dome

IMPORTANT FUNCTION

●  English screen menu display
●  8 channels time action
●  Three-dimensional position magnify
●  ordinate.time display
●  English caption edit
●   Malfunction information checking


IMPORTANT FUNCTION

● Cover structure

 Aluminium alloy crust, 6 inch transparent dome cover, black untransparent dome.
 Base.dome driver.transparent cover fission structure
Embed.indorr.outdoor append installation ways.
 Accord with IP66 standard.CE.FCC standard
 Built-in surge and lightning strike protector
 Dispel heat and temparture control


● Dome driver

8 privacy masking, secrecy district auto tracking and enshroud function
4 piece pattern scan, each piece can record 5-500 minutes
6 auto cruising tracks function, each cruising track set up 18 preset postions, set staying time of each preset position available.
Support alarm linkage, 6 alarm input, 2 alarm output
Multiple auto scan modes, can set the scan speed through built-in menu
Can enter multiple running pattern without users:enter home position, auto scan, pattern scan and auto cruise
Wide angle limited speed, rotate speed slower along with camera zoom increase.
Display controlling protocols.address code and Baud rate after opening, screen menu
High quality stepping motor, differential coefficient driver, run placidly, no dithering, no noise.
Shortcut function key call and amend function
Has camera message display switch.
Soft address amend function.

BASIC FUNCTION
Pan 360°continously rotate, maximum speed 400°/s
Uprightness -2°to 93°, 180°auto flip, maximum speed 400°/s
128 preset position, precision<0.05°
 RS-485 control, controlling protocol PELCO D/P, Baud rate 2400/4800/9600 optional
Auto protect message when power outage

ELECTRIC STANDARD
Input pressure: 18-30VAC, standard 24VAC
Input power: indoor 18W, outdoor with heater 72W
Fuse: 1.6A auto resume

OPERATING TEMPERTURE
Indoor: 0℃to 60℃ continous operating
Outdoor: Maxum 60℃ continous operating, Minumum -50℃ discountinously operating, provent frostbite -40℃ continously operating,
ice out 2.5mm after connecting power within 3 hours.

SC-SO800L series SPEED DOME Description:
