160w 180w 200w Outdoor Led Floodlight America Bridgelux Led Chip With Mw Driver
Specifications:
|
Product Name: |
160W 180W 200W LED flood light |
|
Model No.: |
TLD-TG552-160W 180W 200W |
|
Input Voltage: |
AC90-295V 50/60Hz |
|
LED QTY: |
80W*2/90W*2/100W*2 ( multi-chip COB) |
|
Total Power: |
168W/198W/218W |
|
Driver Efficiency: |
>95% |
|
Harmonic distortion |
<10% |
|
Power Factor(PF): |
>0.95 |
|
LED Efficiency: |
100-110lm/W |
|
Initial Lumen: |
>16000lm/18000lm/20000lm |
|
LED Work Voltage: |
30-36V |
|
Color Temperature: |
WW:2700-4000K,PW:4500-5500K,CW:6000-7500K, Red, Yellow, |
|
Distribution of the light: |
LED+ secondary distribution of the light reflector |
|
The curve of light distribution: |
symmetric expression/circular glare |
|
Protected Grade: |
IP65 |
|
Working Temperature: |
-44-50°C |
|
Working Humidity: |
10 ~ 90%RH |
|
Material for light : |
High purity Aluminum+ toughened glass |
|
Case Color Available: |
Black |
|
Beam Angel Available: |
120° |
|
Life Span: |
>50000hours |
|
N.W/G.W: |
16.00KGS/18.00KGS |
|
Product Dimension: |
L552*W397*H172mm |
|
Warranty: |
3 years |
|
Certificate Approved: |
CE-EMC,CE-LVD, RoHS, C-tick, SAA |
Description:
TLD series Led flood light integrate LED lighting source and the cover of the light, the advantages are no needing extra cover, the volume is small and the weight of the body is light. Which make the led light perfect.
The Lighting source of the led flood light is using super bright big size LED chip, It’ s single led chip with top quality which lumen is up to 120lm/W, Using high efficiency PC lens and sand blast oxidation light cover which can solve the problems such as light loss and color shading. It can assure the uniformity of flux and color.
Using high efficiency thermal conductivity silicon, it’s assured the heat sink of the light, the temperature of the junction is not pass 65 ℃, which is effective controlled the light degradation, the lifespan for the led light is over 30000 hours.
High efficiency intelligence Driver and very professional design which makes the surface temperature of the light body less than 60℃. The life span for the driver is over 30000 hours.
The range for the input voltage is wide. Which make the led flood light are available for the global. Unique protection circuit and exact constant current system assure the abilities such as anti-interference and stability of the light.
Our LED Driver are approved CE CB EMC GS TUV,DC12V,24V are available, which can be used for solar.
