Model: RCL-13 (1 master,3 slave motor)
RCL-22 (2 master,2 slave motor)
1. Main Features:
1.1 New ultrasonic welding, good waterproof.
1.2 Suit for any car models, can connect external remote control and alarms.
1.3 can control 2 doors & 4 doors on/off switch.
1.4 Internal pole patent design,not easy to get stuck and easy to install.
2.Specification:
2.1 Rated voltage:DC12.0V
2.2 direction of rotation:CW CCW
2.3 voltage range:9.0~15.0DCV
2.4 Operating Temperature range:-40℃~+80℃
3. Motor electric performance:
3.1 Measure temperature range:+5℃~+35℃
3.2 relative humidity:+30~90%
3.3 motor model:RC280S-21120-55.5+G (High temperature resistant)
3.4 no-load current:Max:0.14A
3.5 no-load speed:1450 RPM
3.6 Rated load current:Max:0.81A
3.7 Rated load speed:Min:12500PRM
3.8 locked-rotor current:Max:6A
3.9 insulation resistance:Min:800 kΩ
4. Pull Test:
4.1 Measuration Voltage:DC12V
4.2 Measuration temperature:+5℃~+35℃
4.3 measuration dynamics:≥30N
5. Range of motion:18±1mm
6. Water-proof test:
From up and down the direction, spray water 200~250 cc/min every minute,no leakage after 15 minutes test.
7. Life test:
Ambient temperature:+5℃~+35℃
Test voltage:12VDC
Operating times:≥100000 times
