OEM / ODM Black, White and Red Rubber to Metal Bonding With 30 Degree - 95 Degree Hardness

OEM / ODM Black, White and Red Rubber to Metal Bonding with 30 degree - 95 degree Hardness

Description:

Material: NR,CR,NBR,SBR, SILICONE,VITON,EPDM, HNBR, BUNA, etc

Hardness: 30degree-95degree

Mode of production: Compression and injection

Production Capabilty: Rubber compression/injection machines including 150T,200T,250T, 300T and 500T

Size/color: The size and color can be designed by the customer

Rubber Compound: Can be UL, FDA, ROSH or REACH approved, and free test slabs and hardness testers can be offered for customer\'s testing.

Applications:

Rubber/Plastic covered metal from our company is widely used all over the world, the main function is sealed, such as a gas seal, water seal, oil seal etc.

Rubber/Plastic coated metal part shell Composed of a metal shell, a spring and rubber seal part. The metal shell performs as a support. The spring provides the seal lip with radial pressure to avoid lubricant leakage, and the lip prevents dust. Applicable to operating condition with sealing media on one side and dust on the other side.

Specifications:

Material: NBR,HNBR,SBR,EPDM,FPM,SILICONE,VITON,NR,CR, PU

Metal Shell: Low Carbon Steel

Size: Customized /standard /nonstandard

Hardness:30~95 shore A

Color: c, or as your request.

Tolerance:According to your request or ISO standard.

Temperature:Common: -20~100 degrees;

NBR(-40~120°),SILICONE(-50~250°),VITON(-25~250°)etc.

Media: Mineral based hydraulic oil and synthetic hydraulic oil (CLP, HLP, APGL, etc.)

Special features:working environment Non-toxic; oil-resistant; heat resistant; abrasion-resistant; aging resistant; insulation; acid and alkaline resistant; airtight; shock absorption, etc.

Competitive Advantage:

◊ We have own factory and our own production line and R&D.

◊ Our products is mainly export to South-America, Germany and so on.

◊ Our factory has do the OEM service for many years.

◊We do excellent products because of our specialization. Ideal design for your usage .Free modification for molding

◊High quality with good price, short delivery time

◊ Good material, advanced technology

◊ Customer\'s logo is welcome
