Sell 200cc ATV With Zongshen Engine and COC Paper

Model No.:MA200E-2A
Product Origin:China
Brand Name:
Price Terms:FOB, CFR, CIF
Payment Terms:T/T, L/C
Certification:
Description:Features: 1) Max. speed: ≥60km/h 2) Max. load capacity: 150kg 3) Engine type: 4-stroke, air-cooled, single cylinder 4) Cylinder: vertical single 5) Final drive: shaft drive 6) Bore x stroke: 63.5 x 62.2mm 7) Piston displacement: 196.98cc 8) Maximum power: 10kW / 7,500rpm 9) Maximum torque: 13.5N.m / 6,500rpm 10) Starting method: electric 11) Lubrication: press splash 12) Transmission: 4-speed, semi-automatic, with reverse gear, manual clutch 13) Ignition: CDI 14) Fuel tank capacity: 4L 15) Engine oil capacity: 1L 16) Gear oil capacity: 0.2L 17) Compression ratio: 9.2:1 18) Tires: a) Front: 19 x 7 - 8 b) Rear: 18 x 9 - 8 19) Brakes: a) Front: drum b) Rear: drum 20) Suspensions: a) Front suspension: double A arm b) Rear suspension: swing arm 21) Climb degrees: ≥20° 22) Min. turning radium: 2,400mm 23) Battery: 12V, 9Ah 24) With front square light 25) Overall dimensions: 1,585 x 980 x 1,010mm 26) Wheelbase: 1,110mm 27) Seat height: 770mm 28) Ground clearance: 150mm 29) Dry weight: 150kg Outer packing: Carton dimensions: 1,490 x 840 x 770mm N.W.: 130kg G.W.: 165kg Conveyance: Qty/20' FCL: 29pcs Qty/40' FCL: 64pcs Qty/40' HQ: 66pcs
