300t Double Girder Gantry Crane, Shipyard Cranes With Double-Trolley For Ship Building

300t Double Girder Gantry Crane, Shipyard Cranes With Double-Trolley For Ship Building



Descrition:


The gantry cranes are used for a wide variety of steps in ship assembly operations and provide the lifting capacity required throughout the enture production process. Our crane installations already ensure efficient load handling when work is carried out on the metal segments. They also guarantee that loads are precisely positioned - such as large fittings when hull sections are built. Our industrial drives are used to move doors and building segments safely and reliably in shipyards.



Features:

1. Material: All compression structural part of crane’s components chosen material with fine quality and meet regulation. The important material has quality guarantee and inspection report.

2. Welding: In view of important welding seam and stress is more than tension weld of 70% allowance stress, conducting fault detection check and take out 5% weld length by ultrasonic test. Inspection report provided to user.

3. Structure: The gantry frame is mainly including main girders, flexible leg and rigid leg. The flexible and rigid leg structure is specially designed for large span. So the crane keep balance and reduce swinging while traveling.

4. Trolley: Two trolleys with different height. The higher trolley is designed with bigger span than the shorter one. So the room under the higher one is enough for another trolley’s motion. It enables slewing large metal segment.

5. Motor: Drive motor must use China Top Brand: Jiangte Motor. Manufacturer have good achievement used and provided detailed and actual parameter prove that it is good performance product. Insulation class ≧ F; Protective class ≧ IP54.

6. Electric system: Inverter from famous brand ABB can make lifting and traveling in any speed you want specifically for your work.

7. Control panel: Because of big span and height, cabin with joystick panel is the most fitting choice.

8. Painting: All steel is treated by sand blasting before doing paintings. There are 3 layers of paintings. The bottom layer is zinc painting to prevent from rusting.   The color of top surface should be average.

9. Limit switch for safety: mechanical limit switch: overload limit, height limit, rail end stop limit for traveling. Electric protection: short circuit protection, lose phase protection, low-voltage protection, power failure protection, over current protection.

10. Lighting: Adequate lighting under girder for operation at night. With alarm warning while moving for site’s clearance and people’s safety.


Applications:

Mainly used in shipyard with high lifting capacity for construction of hull section.

Specifications:

Competitive Advantage:

1. Light dead-weight, low noise and few faults, generally used in normal working condition.
2. Desiged base on DIN standard from German.
3. Save the power,
