Certification:CE,ISO,FCC
corrosion endurable cold steel concrete slab steel table formwork with No need fasteners
1 No need timber2 High effiency 50m2 per hour one worker could make
3 No need fasteners/coupler
4 Save money than cuplock
Digital steel architectural template supporting combination structure (DSATSCS) ----not wood scaffold.
Our Product
Digital steel architectural template supporting combination structure short for DSATSCS not wood scaffold.
1,Material It is made of high pure cold steel ,it’s thickness is 2 to 2.5 milimeter ,the characteristics of this kind of new material is corrosion endurable ,the flexibility is big,, firm and not easy to be deformed .
2,Specification
Main-Beam The main beam can adjust length within the scope of 1.17m to 4.39m at will, the short spine is used in balcony tolite and so on .
B-1 2.68m to 4.39m
B-2 2.28m to 3.68m
B-3 1.77m to 2.88m
B-4 1.17m to 1.78m
Sub Beam The sub beam has the specification of 1.15m , 0.8m , 0.4m
1.15m
0.80m
0.40m
3,Support efforts
Its supporting pole can put up 3-4 ton ,and the zone between two main beams can bear 2-2.5 ton , and every sub-beam can bear 1 ton . Now the general thickness of the concrete paddled currently is 10-15 centimeters ,and the weight in the same area is 100-150kg at most, so the supporting strength is enough for all buildings
4,Production character :
No.1 : the narrow flexible connection of keel is not only simple to manipulate but also firm and steady.
No.2 : the telescopic keel can be regulateed at your will
No.3: the smart locket connection between vertical and keel is simple and firm .
No.4 : the horizontal pole is light and firm ,the smart fastener is unique
No.5: compared with wooden grider ,it is much preciser and firmer
No.6: it can make the construction site neat and clean ,so it helps to enhance the image of the corporation and demonstrate the strength of the corporation .
No.7: time-saving , material-saving , laber-saving, dependable safety.
No.8: free timber ,it can be reused and help to save energy resource and construction cost .so it is useful for environmental proection .
5,Advantage :
No.1 : high efficiency , free any technique ,it is easy to operate and raise the work efficiency by 600%,(400 square meters can been finished within eight ours by four people )
No.2 : free material , free a nail wire timber tool ,so it can reduce cost and save much timber .
No.3: dependable safety , pure steel structure ,firm structure accessory firm connection safety.
No.4 : clean neat construction site, easy to manage ,helpful to enhance the project image and firmness.
6,Compare of normal scaffold and DSATSCS :
Normal Supporting : Now , the template supporting structure used for concrete at construction site has adopted the structure way of steel and wooden beams .The followings is its disadvantage: labor-wasting and material- wasting . And it is ugly and hard to adjust .In a word, it is of “low efficiency and bad quality”
In order to overcome the disadvantages ,we finally invented the new-style kind of Digital Steel Architecture Template Supporting Combination Structure .The invention of product has supplied a technical gap ,and has won four pieces of nation patent . it is easy to operate and convenient to Install and dismantle .so it is widely-used, time-saving and material-saving . What’s more can save a great deal wood ,iron wire ,nail and so on.
