Aircraft Brake Pad Riveting Machine, CNC Riveting Machine,brake Lining Riveting Machine

JM12QA(Aircraft brake pad riveting machine)

Characteristics:

A.Mechanical turnover,easy assembly rivet

B.Dividing device,automatic alignment and lock

C.5.6 Inches color LCD touch screen

D.Riveting height can be controlled

E.Riveting pressure and speed stepless adjustable

F.Riveting surface smooth & beautiful

G.Applicable for all kinds of specifications and single side or double side brake pad‘s process

JM12Q-A aircraft brake pad riveting machine is special designed for China Southern Airline Service Department developed special purpose riveting machine for process aircraft brake pad, this machine can process various specifications and types of aircraft brake pad such as Boeing aircraft, McDonnell aircraft, and airbus etc.

Specification:

1. ure                              20Kn

2. Stroke                                         30mm

3. cessing ablity               Ф12mm

4. Available working space          145mm

5. Throat depth                           160mm

6. Riveting tool length                   50mm

7. Eccentric angle                           4°

8. Rotation rate                             960rpm

9. Power                                       0.75Kw

10. Physical size                           820mmx850mmx1450mm

11. Net weight                                   320Kg
